570456 Festo Pneumatic Fittings

570456 on Powermatic Associates
Festo

Part#:570456

Alt. Part#:NPQM-D-Q10-S14-P10

Manufacturer:Festo

Category:Pneumatic Fittings

Product Lifecycle:Active

Product description

push-in connector NPQM-D-Q10-S14-P10 Size: Standard, Nominal size: 9 mm, Design structure: Push/pull principle, Operating pressure complete temperature range: -0,95 - 16 bar, Operating medium: Compressed air in accordance with ISO8573-1:2010 [7:-:-]

Product Details

  • Type code
    NPQM-D
  • Information on operating and pilot media
    Operation with oil lubrication possible
  • Housing material
    Brass, nickel-plated
  • Note on materials
    RoHS-compliant
  • Size
    Standard
  • Design
    Push-pull principle
  • Operating pressure for entire temperature range
    -0.95 bar ... 16 bar
  • Pneumatic connection 2
    for pneumatic tubing outside diameter 10 mm
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:-:-]
  • Product weight
    29.5 g
  • Pneumatic connection 1
    Push-in sleeve QS-14
  • Material of tubing seal
    NBR
  • Nominal width
    9 mm
  • Ambient temperature
    -20 °C ... 70 °C
  • Corrosion resistance class (CRC)
    1 - Low corrosion stress

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
