563712 Festo Cable Assemblies

563712 on Powermatic Associates
Festo

Part#:563712

Alt. Part#:NEBC-M9W5-K-5-N-LE3

Manufacturer:Festo

Category:Cable Assemblies

Product Lifecycle:Active

Product description

connecting cable NEBC-M9W5-K-5-N-LE3 Cable identification: with accessories, Product weight: 250 g, Electrical connection 1, function: Field device side, Electrical connection 1, connection type: Cable, Electrical connection 1, connection technology: Open

Product Details

  • Type code
    NEBC
  • Electrical connection 1, number of pins/wires
    5
  • Electrical connection 2, cable outlet
    Angled
  • Electrical connection 2, connection pattern
    00995744
  • Cable designation
    With accessories
  • Electrical connection 1, connection technology
    Open end
  • Electrical connection 2, connection type
    Plug
  • Electrical connection 2, type of mounting
    Screw-type lock
  • Current rating at 40°C
    1.6 A
  • Note on acceptable current load at 40°C
    2.3 A for 0.34 mm² 3.6 A for 0.49 mm²
  • Cable design
    2 x 0.25 mm² + 2 x 0.34 mm² + 0.49 mm² Shielded
  • Degree of protection
    IP65 IP67
  • Contamination level
    1
  • Note on materials
    RoHS-compliant
  • Housing material
    PA TPE-U(PUR)
  • Insulating sheath material
    TPE-U(PUR)
  • Electrical connection 1, function
    Field device end
  • Electrical connection 1, occupied pins/wires
    3
  • Electrical connection 2, function
    Control side
  • Electrical connection 2, connection technology
    M9x0.5
  • Surge resistance
    0.5 kV
  • Cable diameter
    5.5 mm
  • Ambient temperature
    -20 °C ... 80 °C
  • Color cable sheath
    Light gray
  • Material of pin contacts
    Bronze, gold-plated Brass, gold-plated
  • Product weight
    250 g
  • Electrical connection 2, design
    Round
  • Electrical connection 2, number of pins/wires
    5
  • DC operating voltage range
    0 V ... 30 V
  • Cable length
    5 m
  • Wire ends
    Cable end sleeve
  • Corrosion resistance class (CRC)
    1 - Low corrosion stress
  • Material of screw-type lock
    Brass, nickel-plated
  • Electrical connection 1, connection type
    Cable
  • Electrical connection 2, occupied pins/wires
    3
  • Connector cable test conditions
    Test conditions on request
  • Nominal conductor cross section
    0.25 mm² 0.49 mm²
  • Note on degree of protection
    In mounted state
  • Material of cable sheath
    TPE-U(PUR)
  • Housing colour
    Black
  • Cable characteristic
    Suitable for energy chains
  • Bending radius, flexible cable installation
    ≥ 75 mm
  • Ambient temperature with flexible cable installation
    -5 °C ... 80 °C

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
