563711 Festo Cable Assemblies

Product Details

• Electrical connection 1, number of pins/wires
  5
• Electrical connection 2, cable outlet
  Angled
• DC operating voltage range
  0 V ... 30 V
• Surge resistance
  0.5 kV
• Bending radius, flexible cable installation
  ≥ 75 mm
• Ambient temperature
  -20 °C ... 80 °C
• Corrosion resistance class (CRC)
  1 - Low corrosion stress
• Material of screw-type lock
  Brass, nickel-plated
• Product weight
  108 g
• Electrical connection 1, connection technology
  Open end
• Electrical connection 2, connection type
  Plug
• Electrical connection 2, number of pins/wires
  5
• Current rating at 40°C
  1.6 A
• Connector cable test conditions
  Test conditions on request
• Wire ends
  Cable end sleeve
• Ambient temperature with flexible cable installation
  -5 °C ... 80 °C
• Material of cable sheath
  TPE-U(PUR)
• Material of pin contacts
  Bronze, gold-plated Brass, gold-plated
• Cable designation
  With accessories
• Electrical connection 1, occupied pins/wires
  3
Electrical connection 2, connection technology
M9x0.5
Note on acceptable current load at 40°C
2.3 A for 0.34 mm² 3.6 A for 0.49 mm²
Nominal conductor cross section
0.25 mm² 0.49 mm²
Insulating sheath material
TPE-U(PUR)
Electrical connection 1, connection type
Cable
Electrical connection 2, design
Round
Electrical connection 2, connection pattern
00995744
Cable length
2 m
Cable design
2 x 0.25 mm² + 2 x 0.34 mm² + 0.49 mm² Shielded
Note on degree of protection
In mounted state
Note on materials
RoHS-compliant
Housing material
PA TPE-U(PUR)
Type code
NEBC
Electrical connection 1, function
Field device end
Electrical connection 2, function
Control side
Electrical connection 2, occupied pins/wires
3
Electrical connection 2, type of mounting
Screw-type lock
Cable characteristic
Suitable for energy chains
Cable diameter
5.5 mm
Degree of protection
IP65 IP67
Contamination level
1
Color cable sheath
Light gray
Housing colour
Black
