561694 Festo Quarter Turn Actuators

Name: 561694
Brand: Festo

Festo 561694 semi-rotary drive DAPS-4000-090-RS2-F25 single-acting, Namur valves not suited for direct flange-mounting. Size of actuator: 4000, Flange hole pattern: F25, Swivel angle: 90 deg, End-position adjustment range at 0°: -5 - 5 deg, End-position adjustment ran

Part#:561694

Manufacturer:Festo

Alt. Part#:DAPS-4000-090-RS2-F25

Product Lifecycle:Active

Get a quick Quote!

semi-rotary drive DAPS-4000-090-RS2-F25 single-acting, Namur valves not suited for direct flange-mounting. Size of actuator: 4000, Flange hole pattern: F25, Swivel angle: 90 deg, End-position adjustment range at 0°: -5 - 5 deg, End-position adjustment ran

About the manufacturer: Festo is one of the manufacturers that offers Quarter Turn Actuators that you can order at Powermatic Associates site. Festo Corp. has been a top supplier of automation and intelligent automation solutions for more than four decades in the United States and eight decades globally. The company is committed to transforming the manufacturing sector and enhancing business efficiency.

Check out the 561694 Festo price in the box on the right side or send a quick quote.

Product Details

Flange hole pattern
F25
End-position adjusting range at nominal swivel angle
85 deg ... 95 deg
Cushioning
No cushioning
Closing direction
Clockwise closing
Position sensing
None
ATEX category gas
II 2G
Ambient temperature
-20 °C ... 80 °C
Swivel angle
90 deg
Type code
DAPS
Design
Scotch yoke system
Safety integrity level (SIL)
Up to SIL 2 high demand mode Up to SIL 2 low demand mode
ATEX category for dust
II 2D
Operating medium
Compressed air as per ISO 8573-1:2010 [7:4:4]
Corrosion resistance class (CRC)
3 - High corrosion stress
Torque at nominal operating pressure and 90° swivel angle
4166 Nm
Spring return torque with 50° swivel angle
1250 Nm
Product weight
183000 g
Pneumatic connection
G3/8
Seals material
FPM PUR
Size of valve actuator
4000

Depth shaft connection

58 mm

Standard connection for valve

ISO 5211

Nominal operating pressure

5.6 bar

Type of (ignition) protection for dust

Ex h IIIC T85°C...T200°C Db X

End-position adjusting range at 0°

-5 deg ... 5 deg

Mode of operation

Single-acting

Valve connection conforms to standard

VDI/VDE 3845 (NAMUR)

Type of ignition protection for gas

Ex h IIC T6...T3 Gb X

Explosive ambient temperature

-20°C <= Ta <= +60°C

CE marking (see declaration of conformity)

as per EU explosion protection directive (ATEX)

Torque at nominal operating pressure and 50° swivel angle

2750 Nm

Spring return torque at 0° swivel angle

1666 Nm

Spring force

Note on materials

RoHS-compliant

Housing material

Wrought aluminum alloy

Material of screws

High-alloy steel

Shaft material

High-alloy steel

Mounting position

Any

Symbol

00991266

Connection pressure for spring force

3.5 bar

Operating pressure

3.5 bar ... 8.4 bar

Explosion prevention and protection

Zone 1 (ATEX) Zone 22 (ATEX)

Torque at nominal operating pressure and 0° swivel angle

5000 Nm

Note about the torque

The actuator's operating torque must not be higher than the maximum permissible torque listed in ISO 5211, based on the size of the mounting flange and the coupling.

Spring return torque with 90° swivel angle

2500 Nm

Air consumption at 6 bar per cycle 0°-nominal swivel angle-0°

203.7 l

Shaft connection

T55

Cover material

Wrought aluminum alloy

Material number for shaft

1.4305

Information on operating and pilot media

Operation with oil lubrication possible (required for further use)

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
