560372 Festo Vacuum Valves

Product Details

• Degree of protection
  IP40
• Max. cable length
  30 m
• Pneumatic working port
  QS-3
• Nominal width
  1.5 mm
• Manual override
  Non-detenting
• Signal status display
  LED
• Switching time off
  6 ms
• Duty cycle
  100%
• Shock resistance
  Shock test with severity level 2 as per FN 942017-5 and EN 60068-2-27
• Ambient temperature
  -5 °C ... 50 °C
• Pneumatic connection 1
  QS-4
• Seals material
  FPM NBR
• Housing material
  PA-reinforced PPS-reinforced
• Operating medium
  Compressed air as per ISO 8573-1:2010 [7:4:4]
• Storage temperature
  -20 °C ... 60 °C
• Type of mounting
  With through-hole
• Valve function
  2x2/2 closed, monostable
• Standard nominal flow rate
  30 l/min
• Reset method
  Mechanical spring
• Exhaust air function
  Without flow control option
Symbol
00992254
Max. switching frequency
10 Hz
Information on operating and pilot media
Operation with oil lubrication possible (required for further use)
CE marking (see declaration of conformity)
As per EU EMC directive
Pneumatic connection 11
QS-4
Actuation type
Electrical
Operating voltage
24V DC
Width dimension
20 mm
Sealing principle
Soft
Type of control
Direct
Operating pressure, reversible
-0.95 bar ... 0 bar
On switching time
6 ms
Coil characteristics
24 V DC: low-current phase 0.7 W, high-current phase 3.0 W
Vibration resistance
Transport application test with severity level 2 as per FN 942017-4 and EN 60068-2-6
Temperature of medium
-5 °C ... 50 °C
Electrical connection
KMH plug
Pneumatic connection 2
QS-3
Width
20 mm
Operating pressure
0 bar ... 1.5 bar
Type code
MHA1
Mounting position
Any
Flow direction
Non-reversible
Suitability for vacuum
yes
Standard flow rate
30 l/min
Permissible voltage fluctuations
+/- 10 %
Corrosion resistance class (CRC)
2 - Moderate corrosion stress
Product weight
30.6 g
Note on materials
Free of copper and PTFE RoHS-compliant
Material of screws
Steel
