550077 Festo Pneumatic Valves Accessories
Part#:550077
Alt. Part#:CPE10-PRS-1/4-9-NPT
Manufacturer:Festo
Category:Pneumatic Valves Accessories
Product Lifecycle:Active
Product description
manifold block CPE10-PRS-1/4-9-NPT For CPE valves. Grid dimension: 16 mm, Assembly position: Any, Max. number of valve positions: 9, Max. no. of pressure zones: 2, Operating pressure: -13 - 145 Psi
Product Details
- Pneumatic connection 3 1/4 NPT
- Type code CPE10-PRS
- Operating pressure -0.896 bar ... 9.997 bar
- Max. tightening torque for valve mounting 1.22 Nm
- Width dimension 16 mm
- Max. no. of pressure zones 2
- Temperature of medium -5 °C ... 50 °C
- Manifold block type of mounting With through-hole
- Pneumatic connection 5 1/4 NPT
- Max. no. of valve positions 9
- Ambient temperature -5 °C ... 50 °C
- Pneumatic valve mounting type With internal thread
- Note on materials RoHS-compliant
- Mounting position Any
- Corrosion resistance class (CRC) 2 - Moderate corrosion stress
- Pneumatic connection 1 1/4 NPT
- Manifold rail material Wrought aluminum alloy
- Product weight 463.381 g
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
