549103 Festo Pneumatic Valves Accessories

549103 on Powermatic Associates
Festo

Part#:549103

Alt. Part#:VABF-S1-1-L1D1-C

Manufacturer:Festo

Category:Pneumatic Valves Accessories

Product Lifecycle:Active

Product description

vertical pressure shut-off plate VABF-S1-1-L1D1-C For valve terminal VTSA, standard port pattern to 5599-1, 5599-2, for mounting between manifold sub-base and valve, supply pressure of the terminal is blocked. Width: 42 mm, Based on the standard: ISO 5599

Product Details

  • Pneumatic vertical stacking
    Shut-off for 1
  • Information on operating and pilot media
    Operation with oil lubrication possible (required for further use)
  • Vertical stacking mounting type
    On manifold sub-base On individual sub-base
  • Type code
    VABF
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:4:4]
  • Product weight
    600 g
  • Width
    42 mm
  • Symbol
    00991890
  • Corrosion resistance class (CRC)
    0 - No corrosion stress
  • Note on materials
    RoHS-compliant
  • Based on norm
    ISO 5599-1
  • Standard nominal flow rate
    1200 l/min
  • Ambient temperature
    -5 °C ... 50 °C
  • Mounting position
    Any
  • Operating pressure
    -0.09 MPa ... 1 MPa
  • Degree of protection
    IP65 NEMA 4
  • Housing material
    Die-cast aluminum

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
