547888 Festo Cable Assemblies

Product Details

• Additional functions
  Distribution of the analog inputs and outputs of a proportional pressure control valve
• Electrical connection 1, connection type
  Socket
• Electrical connection 1, occupied pins/wires
  5
• Electrical connection 2, cable outlet
  Straight
• Electrical connection 2, connection pattern
  00995386
• Electrical connection 3, connection technology
  M12x1 A-coded as per EN 61076-2-101
• Electrical connection for input 3, connection pattern
  00995635
• Surge resistance
  0.8 kV
• Bending radius 1, flexible cable installation
  ≥ 66 mm
• Cable diameter 2
  6.3 mm
• Degree of protection
  IP67
• Ambient temperature with flexible cable installation
  -5 °C ... 80 °C
• Contamination level
  3
• Housing material
  TPE-U(PUR)
• Material of pin contacts
  Brass, nickel-plated and gold-plated
• Distributor type
  1 to 2
• Electrical connection 1, cable outlet
  Straight
• Electrical connection 1, type of mounting
  Screw-type lock
• Electrical connection 2, connection type
  Plug
• Electrical connection 2, number of pins/wires
  4
Electrical connection 3, design
Round
DC operating voltage range
0 V ... 30 V
Bending radius 1, fixed cable installation
≥ 33 mm
Bending radius 2, flexible cable installation
≥ 66 mm
Cable diameter 2 tolerance
± 0.2 mm
Ambient temperature
-25 °C ... 80 °C
Color cable sheath
Gray
Insulating sheath material
PP
Conforms to standard
DIN 47100 EN 61076-2-101
Electrical connection 1, function
Field device end
Electrical connection 1, design
Round
Electrical connection 2, function
Control side
Electrical connection 2, type of mounting
Screw-type lock
Electrical connection 3, connection type
Plug
Electrical connection 3, number of pins/wires
4
Cable length 1
2.5 m
Bending radius 2, fixed cable installation
≥ 33 mm
Cable diameter tolerance 1
± 0.2 mm
Nominal conductor cross section
0.25 mm²
CE marking (see declaration of conformity)
As per EU EMC directive
Material of cable sheath
TPE-U(PUR)
Housing colour
Black
Design
Y-distributor with cables at both ends
Type of mounting
With through-hole for M3 screw
Electrical connection 1, number of pins/wires
8
Electrical connection 2, connection technology
M12x1 A-coded as per EN 61076-2-101
Electrical connection 3, function
Control side
Electrical connection 3, occupied pins/wires
3
Current rating at 40°C
2 A
Cable characteristic
Standard
Note on degree of protection
In mounted state
Corrosion resistance class (CRC)
2 - Moderate corrosion stress
Material of screw-type lock
Brass, nickel-plated
Type code
NEBV
Cable designation
Without label holder
Electrical connection 1, connection technology
M12x1 A-coded as per EN 61076-2-101
Electrical connection for input 1, connection pattern
00992265
Electrical connection 2, design
Round
Electrical connection 2, occupied pins/wires
4
Electrical connection 3, cable outlet
Straight
Electrical connection 3, type of mounting
Screw-type lock
Operating voltage range AC
0 V ... 30 V
Cable length 2
0.5 m
Cable diameter 1
6.3 mm
Cable design
8 x 0.25 mm² Shielded
Note on materials
RoHS-compliant Halogen-free
Seals material
NBR
