547710 Festo Vacuum Generators

Product Details

• Symbol
  00991489
• Nominal operating pressure
  6 bar
• Temperature of medium
  0 °C ... 60 °C
• Pneumatic connection 1
  QS-6
• Housing material
  POM-reinforced
• Material of pneumatic fitting
  Brass Nickel-plated
• Ambient temperature
  0 °C ... 60 °C
• Muffler construction type
  Open
• Operating pressure for max. suction rate
  8 bar
• Max. suction rate with respect to atmosphere
  90 l/min
• Noise level at nominal operating pressure
  77 dB(A)
• Max. tightening torque
  0.5 Nm
• Pneumatic connection 3
  Pneumatic muffler open
• Material of jet nozzle
  Wrought aluminum alloy
• Nominal width of Laval nozzle
  1.4 mm
• Type code
  VN
• Integrated function
  Pneumatic muffler open
• Operating medium
  Compressed air as per ISO 8573-1:2010 [7:4:4]
• Vacuum connection
  QS-8
• Seals material
  NBR
Width dimension
18 mm
Ejector characteristics
High suction rate Standard
Design
T-shape
Corrosion resistance class (CRC)
1 - Low corrosion stress
Type of mounting
With through-hole With accessories
Female nozzle material
POM
Muffler material
Die-cast aluminum PU foam
Mounting position
Any
Operating pressure
1 bar ... 8 bar
Air supply time at nominal operating pressure
0.25 s
Information on operating and pilot media
Operation with oil lubrication not possible
Product weight
36 g
Note on materials
Free of copper and PTFE RoHS-compliant
