547271 Festo Cable Assemblies

547271 on Powermatic Associates
Festo

Part#:547271

Alt. Part#:KMEB-3-24-5

Manufacturer:Festo

Category:Cable Assemblies

Product Lifecycle:Active

Product description

plug socket with cable KMEB-3-24-5 For VUVB solenoid valves with 24 V coils. Mounting type: On solenoid valve with M2.5 central screw, Assembly position: Any, Product weight: 230 g, Electrical connection: (* 2-pin, * Plug socket angled, * Plug pattern typ

Product Details

  • Type of mounting
    On air solenoid valve with M2.5 central screw
  • Cable length
    5 m
  • Degree of protection
    IP65 as per IEC 60529
  • CE marking (see declaration of conformity)
    As per EU RoHS directive
  • Product weight
    230 g
  • Protective earth connection
    Not available
  • Ambient temperature
    -20 °C ... 80 °C
  • Housing material
    PC
  • Cable characteristic
    Standard
  • Cable diameter
    5.2 mm
  • Corrosion resistance class (CRC)
    1 - Low corrosion stress
  • Mounting position
    Any
  • Type code
    KMEB
  • Nominal operating voltage DC
    24 V
  • Cable design
    2 x 0.75 mm²
  • Material of pin contacts
    Bronze Silver-plated
  • Electrical connection
    2-pin as per DIN EN 175301-803
  • Reverse polarity protection
    for all electrical connections
  • Material of cable sheath
    PVC

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
