546188 Festo Valve Manifold Accessories

Product Details

• Device-specific diagnostics
  Via device-specific diagnostics (DPV0) Undervoltage of pneumatic valves
• Configuration support
  GSD file and bitmaps
• DC operating voltage range
  20.4 V ... 26.4 V
• Max. number of inputs
  32
• Corrosion resistance class (CRC)
  1 - Low corrosion stress
• Storage temperature
  -20 °C ... 70 °C
• Galvanic isolation fieldbus interface
  Optocoupler
• LED display (bus-specific)
  BUS: communication and configuration error
• Cover material
  PA-reinforced
• Seals material
  CR NBR
• Communication types
  Cyclic communication
• Reverse polarity protection
  for all electrical connections
• Nominal operating voltage DC
  24 V
• Power failure buffering
  10 ms
• Fieldbus certification
  PNO
• LED display (product-specific)
  12/14: switching status of pneumatic valves POWER: operating voltage for electronics and load supply
• Note on materials
  RoHS-compliant
• CP string extension
  yes 32 outputs
• Max. no. of solenoid coils with string extension
  48
• Max. no. of outputs
  16 valve coils and 32 outputs 48 valve coils
Current consumption at nominal operating voltage
Electronics: <= 100 mA Sensor supply: depends on sensor
Degree of protection
IP65
Certification
c UL us - Recognized (OL)
Fieldbus interface
Optionally: Sub-D, 9-pin, socket
Baud rate
9.6 kBd ... 12 MBaud Automatic detection
Current consumption at load nominal operating voltage
Depends on pneumatic valve type
Addressing range
1 ... 125 Setting via switch module
Housing material
Die-cast aluminum
Type code
CPV10
Max. no. of solenoid coils
16
Residual ripple
4 Vss
Ambient temperature
-5 °C ... 50 °C
Product identification
Product line: 4: pneumatic valves
