540156 Festo Pneumatic Valves Accessories

540156 on Powermatic Associates
Festo

Part#:540156

Alt. Part#:VABF-S4-1-R3C2-C-6

Manufacturer:Festo

Category:Pneumatic Valves Accessories

Product Lifecycle:Active

Product description

regulator plate VABF-S4-1-R3C2-C-6 For valve terminals VTSA and VTSA-F, standard port pattern to 15407-2, up to max. 6 bar. Width: 26 mm, Based on the standard: ISO 15407-2, Assembly position: Any, Controller function: (* Output pressure constant, * with

Product Details

  • Mounting position
    Any
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:4:4]
  • Material of operator panel
    PA
  • Ambient temperature
    -5 °C ... 50 °C
  • Based on norm
    ISO 15407-2
  • Operating pressure
    0.6 MPa
  • Pilot medium
    Compressed air as per ISO 8573-1:2010 [7:4:4]
  • Vertical stacking mounting type
    On manifold sub-base On individual sub-base
  • Width
    26 mm
  • Optional pressure gauge
    Possible
  • Corrosion resistance class (CRC)
    0 - No corrosion stress
  • Degree of protection
    IP65 NEMA 4
  • Pressure gauge connection
    With retaining clamp
  • Type code
    VABF
  • Controller function
    Outlet pressure constant With secondary exhausting
  • Pressure regulation range
    2 bar ... 6 bar
  • CE marking (see declaration of conformity)
    As per EU low voltage directive
  • Controller housing material
    Die-cast aluminum
  • Symbol
    00991579
  • Inlet pressure 1
    0.5 bar ... 10 bar
  • Information on operating and pilot media
    Operation with oil lubrication possible (required for further use)
  • Product weight
    448 g

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
