532622 Festo Vacuum Generators

Product Details

• Type code
  VN
• Ejector characteristics
  Standard High negative pressure
• Operating pressure for max. suction rate
  3 bar
• Nominal operating pressure
  6 bar
• Information on operating and pilot media
  Operation with oil lubrication not possible
• Product weight
  62 g
• Pneumatic connection 1
  QS-6
• Female nozzle material
  POM
• Material of screws
  Steel
• Width dimension
  14 mm
• Manual override
  Non-detenting
• Design
  T-shape
• Electrical power consumption
  1.2 W
• Corrosion resistance class (CRC)
  1 - Low corrosion stress
• Degree of protection
  IP40
• Type of mounting
  With through-hole With accessories
• Note on materials
  Free of copper and PTFE RoHS-compliant
• Muffler material
  PE
• Muffler construction type
  Open
• Symbol
  00991944
Operating pressure for max. vacuum
4.9 bar
Max. suction rate with respect to atmosphere
7.2 l/min
Air supply time at nominal operating pressure
3.9 s
Electrical connection
Plug
Pneumatic connection 3
Pneumatic muffler open
Seals material
NBR
Material of connecting thread
Wrought aluminum alloy, anodized
Material of jet nozzle
Wrought aluminum alloy
Nominal width of Laval nozzle
0.45 mm
Mounting position
Any
Valve function
2/2
Max. vacuum
92 %
Duty cycle
100%
Temperature of medium
0 °C ... 50 °C
Noise level at nominal operating pressure
56 dB(A)
Vacuum connection
QS-6
Housing material
PA-reinforced POM-reinforced
Material of pneumatic fitting
Brass Nickel-plated
Integrated function
Ejector pulse valve, pneumatic Pneumatic muffler open
Operating pressure
2 bar ... 8 bar
DC operating voltage range
21.6 V ... 26.4 V
Operating medium
Compressed air as per ISO 8573-1:2010 [7:4:4]
Ambient temperature
0 °C ... 50 °C
