529992 Festo Compressed Air Preparation Units

529992 on Powermatic Associates
Festo

Part#:529992

Alt. Part#:MS6-LR-1/2-D6-AS-Z

Manufacturer:Festo

Category:Compressed Air Preparation Units

Product Lifecycle:Active

Product description

pressure regulator MS6-LR-1/2-D6-AS-Z 7 bar maximum output pressure, with pressure gauge, lockable regulator head, direction of flow: from right to left. Size: 6, Series: MS, Actuator lock: (* Rotary knob with lock, * with accessories, lockable), Assembly

Product Details

  • Size
    6
  • For use in the food industry
    See supplementary material information
  • Design
    Pressure regulator with pressure gauge
  • Max. pressure hysteresis
    0.25 bar
  • Information on operating and pilot media
    Operation with oil lubrication possible (required for further use)
  • Type code
    MS6-LR
  • Symbol
    00991558
  • Pneumatic connection 1
    G1/2
  • Material of operator panel
    PA POM
  • Separating disc material
    POM
  • Series
    MS
  • Operating pressure
    0.8 bar ... 20 bar
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:4:4] Inert gas
  • Controller function
    Outlet pressure constant With secondary exhausting
  • Corrosion resistance class (CRC)
    2 - Moderate corrosion stress
  • Ambient temperature
    -10 °C ... 60 °C
  • Standard nominal flow rate
    6500 l/min
  • Product weight
    730 g
  • Actuator lock
    Rotary knob with detent can be closed with accessories
  • Pressure gauge
    with pressure gauge
  • Storage temperature
    -10 °C ... 60 °C
  • Housing material
    Die-cast aluminum
  • Temperature of medium
    -10 °C ... 60 °C
  • Type of mounting
    Optionally: With accessories
  • Pneumatic connection 2
    G1/2
  • Seals material
    NBR
  • Mounting position
    Any
  • Pressure regulation range
    0.3 bar ... 7 bar
  • Note on materials
    RoHS-compliant
  • Compressed air filter material
    PE
  • Diaphragm material
    NBR

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

529992 Related Documents

529992 DataSheet.pdf
