5105631 Festo Pneumatic Components

Product Details

• Type code
  SIM
• Electrical connection 1, design
  Round
• Electrical connection 1, number of pins/wires
  8
• Electrical connection for input 1, connection pattern
  00992265
• Operating voltage range AC
  0 V ... 30 V
• Cable length
  15 m
• Cable diameter
  6.3 mm
• Note on degree of protection
  In mounted state
• Wire ends
  Tin-plated
• Color cable sheath
  Gray
• Insulating sheath material
  PP
• Conforms to standard
  DIN 47100 EN 61076-2-101
• Electrical connection 1, cable outlet
  Straight
• Electrical connection 2, connection type
  Cable
• Electrical connection 2, occupied pins/wires
  8
• Cable design
  8 x 0.25 mm² Shielded
• Degree of protection
  IP67
• Corrosion resistance class (CRC)
  2 - Moderate corrosion stress
• Material of cable sheath
  TPE-U(PUR)
• Cable designation
  Without label holder
Electrical connection 1, connection type
Socket
Electrical connection 2, function
Control side
Surge resistance
0.8 kV
Bending radius, fixed cable installation
≥ 32 mm
Nominal conductor cross section
0.25 mm²
Ambient temperature with flexible cable installation
-5 °C ... 80 °C
CE marking (see declaration of conformity)
As per EU EMC directive
Material of screw-type lock
Brass, nickel-plated
Electrical connection 1, occupied pins/wires
8
Electrical connection 2, number of pins/wires
8
Cable characteristic
Standard
Cable diameter tolerance
± 0.2 mm
Contamination level
3
Material of pin contacts
Bronze, gold-plated
Electrical connection 1, function
Field device end
Electrical connection 1, connection technology
M12x1 A-coded as per EN 61076-2-101
Electrical connection 1, type of mounting
Screw-type lock
Electrical connection 2, connection technology
Open end
Current rating at 40°C
2 A
DC operating voltage range
0 V ... 30 V
Bending radius, flexible cable installation
≥ 66 mm
Ambient temperature
-25 °C ... 85 °C
Note on materials
RoHS-compliant
Housing material
TPE-U(PUR)
