5105625 Festo Cable Assemblies

Product Details

• Electrical connection 1, design
  Round
• Electrical connection 1, number of pins/wires
  8
• Electrical connection 2, function
  Control side
• Electrical connection 2, occupied pins/wires
  8
• Cable characteristic
  Suitable for energy chains
• Cable design
  4 x 2 x 0.14 mm² Shielded
• Degree of protection
  IP65
• Note on materials
  RoHS-compliant
• Cable designation
  Without label holder
• Electrical connection 1, cable outlet
  Straight
• Electrical connection 2, connection technology
  Sub-D
• DC operating voltage range
  0 V ... 30 V
• Bending radius, flexible cable installation
  ≥ 49 mm
• Ambient temperature
  -40 °C ... 70 °C
• Electrical connection 1, function
  Field device end
• Electrical connection 1, connection type
  Socket
• Electrical connection 2, design
  Rectangular
• Electrical connection 2, number of pins/wires
  9
• Electrical connection 2, connection pattern
  00995639
• Nominal operating voltage AC
  24 V
Cable diameter
6.5 mm
Color cable sheath
Gray
Electrical connection 1, occupied pins/wires
8
Electrical connection 2, connection type
Plug
Operating voltage range AC
0 V ... 30 V
Cable length
20 m
Note on degree of protection
IP30 for Sub-D plug In mounted state
CE marking (see declaration of conformity)
As per EU RoHS directive
Material of cable sheath
TPE-U(PUR)
Type code
NEBM
Electrical connection 1, connection technology
M12x1 A-coded as per EN 61076-2-101
Electrical connection for input 1, connection pattern
00992265
Electrical connection 2, cable outlet
Straight
Nominal operating voltage DC
24 V
Nominal conductor cross section
0.14 mm²
Ambient temperature with flexible cable installation
-40 °C ... 70 °C
