4500004 Festo Mechanical & Manual Valves
Part#:4500004
Alt. Part#:VHEF-L-M52-E-G14
Manufacturer:Festo
Category:Mechanical & Manual Valves
Product Lifecycle:Active
Product description
finger lever valve VHEF-L-M52-E-G14 Valve function: 5/2 monostable, Type of actuation: manual, Width: 20 mm, Standard nominal flow rate: 1200 l/min, Operating pressure MPa: -0,095 - 1 MPa
Product Details
- Valve function 5/2, monostable
- Width 20 mm
- Application note Operate by hand only
- Operating medium Compressed air as per ISO 8573-1:2010 [7:-:-]
- Type of mounting With through-hole
- Pneumatic connection 4 G1/4
- Lap Overlap
- Actuation type Manual
- Sealing principle Soft
- Information on operating and pilot media Operation with oil lubrication possible (required for further use)
- Pilot air port 12/14 M5
- Pneumatic connection 5 G1/4
- Design Piston gate valve
- Type code VHEF
- Flow direction Reversible
- Explosion prevention and protection Zone 1 (ATEX) Zone 22 (ATEX)
- Ambient temperature -10 °C ... 60 °C
- Pneumatic connection 2 G¼
- Pneumatic connection 3 G1/4
- Operating pressure -0.95 bar ... 10 bar
- Pneumatic working port G1/4
- Nominal width 7 mm
- Mounting position Any
- Symbol 00992191
- Temperature of medium -10 °C ... 60 °C
- Product weight 217 g
- Seals material NBR
- Lever material PA-reinforced
- Cover material PA-reinforced
- Standard nominal flow rate 1200 l/min
- Reset method Pneumatic spring
- Exhaust air function With flow control option
- Type of control Direct
- Max. switching frequency 0.5 Hz
- Corrosion resistance class (CRC) 1 - Low corrosion stress
- Actuating force 14 N
- Pneumatic connection 1 G1/4
- Note on materials RoHS-compliant
- Housing material Wrought aluminum alloy, anodized
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
