345395 Festo Pressure Gauges

345395 on Powermatic Associates
Festo

Part#:345395

Alt. Part#:MA-40-16-1/8

Manufacturer:Festo

Category:Pressure Gauges

Product Lifecycle:Active

Product description

pressure gauge MA-40-16-1/8 Indicating range [bar]: 0 - 16 bar, Conforms to standard: EN 837-1, Nominal size of pressure gauge: 40, Design structure: Bourdon-tube pressure gauge, Mounting type: Line installation

Product Details

  • Operating pressure
    0 bar ... 16 bar
  • Degree of protection
    IP43
  • Note on materials
    RoHS-compliant
  • Product weight
    60 g
  • Symbol
    00991463
  • Explosion prevention and protection
    Observe the information on the certificate Zone 22 (ATEX)
  • Measurement accuracy class
    2.5
  • Ambient temperature
    -20 °C ... 60 °C
  • Housing colour
    Black
  • Display range
    0 bar ... 16 bar
  • Operating medium
    Inert gas Neutral liquids
  • Intermittent load factor
    0.66
  • Pneumatic connection
    G1/8
  • Housing material
    ABS
  • Information on operating and pilot media
    No acetylene No oxygen
  • Conforms to standard
    EN 837-1
  • Type of mounting
    Line installation
  • Connection position
    Centered on rear side
  • Materials in contact with the media
    Brass
  • Type code
    MA
  • Pressure gauge nominal size
    40
  • Design
    Bourdon tube pressure gauge
  • Temperature of medium
    -20 °C ... 60 °C
  • Material of screwed trunnion
    Brass
  • Inspection window material
    PS

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
