3192085 Festo Mechanical & Manual Valves

Product Details

• Flow direction
  Non-reversible
• Underlap
  yes
• Design
  Rotary gate valve
• Actuation type
  Manual
• Operating pressure
  0 bar ... 10 bar
• Symbol
  00995942
• Information on operating and pilot media
  Operation with oil lubrication possible (required for further use)
• Product weight
  1010 g
• Pneumatic connection 3
  NPT1/2-14
• Housing material
  Die-cast aluminum
• Standard nominal flow rate
  3200 l/min
• Type code
  VHER
• Type of control
  Direct
• Corrosion resistance class (CRC)
  2 - Moderate corrosion stress
• Pneumatic connection 1
  NPT1/2-14
• Width
  95 mm
• Information on operating pressure
  Vacuum operation at connection 3 only In dual pressure mode, the pressure at connection 1 must be higher than at connection 3.
• Exhaust air function
  With flow control option
• Sealing principle
  Hard
• Operating medium
  Compressed air as per ISO 8573-1:2010 [7:4:4]
Ambient temperature
-20 °C ... 80 °C
Actuating torque
5 Nm
Pneumatic connection 4
NPT1/2-14
Lever material
Die-cast aluminum
Valve function
4/3, closed
Pneumatic working port
NPT1/2-14
Nominal width
12 mm
Application note
Operate by hand only
Switching position indication
with accessories
Type of mounting
Optionally: With through-hole
Note on materials
Free of copper and PTFE RoHS-compliant
Temperature of medium
-20 °C ... 80 °C
Pneumatic connection 2
NPT1/2-14
Seals material
NBR
