2798071 Festo Electrical Peripheral Devices

Product Details

• Type code
  CTEU
• Parameterization
  Diagnostic behavior Fail-safe and idle response
• Intrinsic current consumption at nominal operating voltage
  Typ. 65 mA
• Corrosion resistance class (CRC)
  2 - Moderate corrosion stress
• Note on materials
  Contains paint-wetting impairment substances RoHS-compliant
• Configuration support
  EDS file
• Nominal operating voltage DC
  24 V
• Degree of protection
  IP65 IP67
• Product weight
  98 g
• LED display (bus-specific)
  NS: network status TP2: network active, port 2
• Dimensions W x L x H
  40 mm x 91 mm x 50 mm
• Additional functions
  AddressConflictDetection (ACD) Web server
• Internal cycle time
  1 ms per 1 byte of user data
• CE marking (see declaration of conformity)
  As per EU EMC directive
• Storage temperature
  -20 °C ... 70 °C
• Max. address capacity inputs
  64 byte
• Fieldbus interface
  2x socket, M12x1, 4-pin, D-coded
• Baud rate
  10/100 Mbit/s
• Protocol
  EtherNet/IP Modbus® TCP
• Ambient temperature
  -5 °C ... 50 °C
LED display (product-specific)
PS: operating voltage for electronics and load supply X2: module system status at I-Port 2
KC characters
KC EMC
Diagnostics
Communication error Undervoltage
Control elements
DIL switch
DC operating voltage range
18 V ... 30 V
Max. power supply
4 A
Max. address capacity outputs
64 byte
Certification
RCM compliance mark c UL us - Listed (OL)
Housing material
PA
