2089699 Festo Servo Motors
Part#:2089699
Alt. Part#:EMME-AS-60-S-LS-AM
Manufacturer:Festo
Category:Servo Motors
Product Lifecycle:Active
Product description
servo motor EMME-AS-60-S-LS-AM Without gearing, without brake. Ambient temperature: -10 - 40 °C, Storage temperature: -20 - 70 °C, Relative air humidity: 0 - 90 %, Conforms to standard: IEC 60034, Insulation protection class: F
Product Details
- Rotor position sensor interface HIPERFACE®
- Nominal rotary speed 3000 1/min
- Nominal operating voltage DC 360 V
- Rotor position encoder, typical angular accuracy 20 arcmin
- Type of winding switch Star inside
- Rating class according to EN 60034-1 S1
- Degree of protection IP21
- Total output inertia moment 0.22 kgcm²
- Permissible radial shaft load 250 N
- Electrical connection technology Plug
- Number of pole pairs 3
- Rotor position sensor Absolute encoder, multi-turn
- Continuous stall current 0.9 A
- DC nominal voltage 360 V
- Phase-phase winding resistance 26.4 Ohm
- CE marking (see declaration of conformity) As per EU EMC directive As per EU low voltage directive
- Certification RCM compliance mark c UL us - Recognized (OL)
- Permissible axial shaft load 50 N
- Product weight 1300 g
- Rotor position sensor measuring principle Capacitive
- Insulation protection class F
- Motor nominal power 190 W
- Rotor position encoder, sinusoidal/cosinusoidal periods per revolution 16
- Voltage constant, phase-to-phase 49.6 mVmin
- Relative air humidity 0 - 90 %
- Nominal torque 0.6 Nm
- Conforms to standard IEC 60034
- Type code EMME-AS
- Max. rotational speed 5131 1/min
- Motor constants 0.75 Nm/A
- Motor nominal current 0.8 A
- Winding inductance phase-phase 31.9 mH
- Peak current 3.6 A
- Storage temperature -20 °C ... 70 °C
- Ambient temperature -10 °C ... 40 °C
- Stall torque 0.7 Nm
- MTTFd, subcomponent 271 years, rotor position sensor
- Typical rotor position sensor resolution 12 bit
- Corrosion resistance class (CRC) 0 - No corrosion stress
- Peak torque 2.8 Nm
- Note on materials Contains paint-wetting impairment substances RoHS-compliant
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
