2082430 Festo Servo Motors

Product Details

• Brake DC operating voltage
  24 V
• Motor nominal current
  0.7 A
• Phase-phase winding resistance
  25.6 Ohm
• Voltage constant, phase-to-phase
  13.5 mVmin
• Relative air humidity
  0 - 90 %
• Brake holding torque
  0.4 Nm
• Peak torque
  0.7 Nm
• Permissible axial shaft load
  12 N
• Conforms to standard
  IEC 60034
• Type code
  EMME-AS
• Nominal rotary speed
  9000 1/min
• Nominal operating voltage DC
  360 V
• Rotor position encoder, typical angular accuracy
  20 arcmin
• Winding inductance phase-phase
  9.95 mH
• CE marking (see declaration of conformity)
  As per EU EMC directive As per EU low voltage directive
• Ambient temperature
  -10 °C ... 40 °C
• Total output inertia moment
  0.055 kgcm²
• MTTFd, subcomponent
  340 years, rotor position sensor
• Note on materials
  Contains paint-wetting impairment substances RoHS-compliant
• Rotor position sensor interface
  HIPERFACE®
Motor constants
0.171 Nm/A
DC nominal voltage
360 V
Peak current
3.2 A
Degree of protection
IP21
Brake mass moment of inertia
0.014 kgcm²
Stall torque
0.18 Nm
Electrical connection technology
Plug
Number of pole pairs
2
Max. rotational speed
10000 1/min
Brake power consumption
8 W
Continuous stall current
0.8 A
Typical rotor position sensor resolution
12 bit
Type of winding switch
Star inside
Storage temperature
-20 °C ... 70 °C
Corrosion resistance class (CRC)
0 - No corrosion stress
Nominal torque
0.12 Nm
Permissible radial shaft load
105 N
Product weight
650 g
Rotor position sensor
Absolute encoder, single-turn
Rotor position sensor measuring principle
Capacitive
Insulation protection class
F
Motor nominal power
110 W
Rotor position encoder, sinusoidal/cosinusoidal periods per revolution
16
Rating class according to EN 60034-1
S1
Certification
RCM compliance mark c UL us - Recognized (OL)
MTTF, subcomponent
371 years, holding brake
Switching cycles, holding brake
5 million idle actuations (without friction work!)
