192566 Festo Compressed Air Preparation Units

192566 on Powermatic Associates
Festo

Part#:192566

Alt. Part#:LFMA-D-MINI-A

Manufacturer:Festo

Category:Compressed Air Preparation Units

Product Lifecycle:Active

30 in stock

Apr 24, 2025

Product description

micro filter LFMA-D-MINI-A Without threaded connection plates with FRB threaded pin. 0.01 µm filter cartridge, with metal bowl guard. Series: D, Size: Mini, Design structure: Fibre filter, Grade of filtration: 0,01 µm, Condensate drain: fully automatic

Product Details

  • Size
    Mini
  • Operating pressure
    2 bar ... 12 bar
  • Temperature of medium
    1.5 °C ... 60 °C
  • Pneumatic connection 1
    Sub-base
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [6:8:4] Inert gas
  • Bowl guard
    Metal bowl guard
  • Residual oil content
    0.01 mg/m³
  • Housing material
    Die-cast zinc
  • Series
    D
  • Grade of filtration
    0.01 µm
  • Symbol
    00991520
  • Mounting position
    Vertical +/- 5°
  • Note on materials
    Free of copper and PTFE RoHS-compliant
  • Type code
    LFMA
  • Air quality class at the output
    Compressed air as per ISO 8573-1:2010 [1:7:2] Inert gas
  • Corrosion resistance class (CRC)
    2 - Moderate corrosion stress
  • Material of bowl
    PC
  • Design
    Fiber filter
  • Pneumatic connection 2
    Sub-base
  • Compressed air filter material
    Borosilicate fiber
  • Condensate drain
    Fully automatic
  • Ambient temperature
    -10 °C ... 60 °C
  • Filter efficiency
    99.9999 %
  • Type of mounting
    Optionally: With accessories

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
