189418 Festo Vacuum Cups

189418 on Powermatic Associates
Festo

Part#:189418

Alt. Part#:ESS-30X90-ON

Manufacturer:Festo

Category:Vacuum Cups

Product Lifecycle:Active

Product description

suction cup ESS-30X90-ON easily interchangeable, Nominal size: 6 mm, suction cup size: 30x90 mm, suction cup volume: 10,17 cm3, Position of connection: on top, Assembly position: Any

Product Details

  • Mounting position
    Any
  • Nominal operating pressure
    -0.7 bar
  • Ambient temperature
    -10 °C ... 70 °C
  • Shore hardness
    50 +/- 5
  • Connection position
    Top
  • Classification of suction cup holder
    Size 5
  • Vertical lateral force at nominal operating pressure
    134.5 N
  • Type of mounting
    Via vacuum connection
  • Note on materials
    Free of copper and PTFE RoHS-compliant
  • Suction cup volume
    10.17 cm³
  • Operating pressure
    0 bar ... 0.95 bar
  • Corrosion resistance class (CRC)
    1 - Low corrosion stress
  • Holding force at nominal operating pressure
    134.4 N
  • Vacuum connection
    M10
  • Vacuum cup size
    30x90 mm
  • Suction cup shape
    Oval, flat
  • For use in the food industry
    See supplementary material information
  • Product weight
    55.3 g
  • Suction cup material
    NBR
  • Nominal width
    6 mm
  • Type code
    ESS
  • Symbol
    00991485
  • Operating medium
    Atmospheric air based on ISO 8573-1:2010 [7:-:-]
  • Horizontal lateral force at nominal operating pressure
    201 N
  • Color
    Black

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
