189403 Festo Vacuum Cups

189403 on Powermatic Associates
Festo

Part#:189403

Alt. Part#:ESS-30-CS

Manufacturer:Festo

Category:Vacuum Cups

Product Lifecycle:Active

Product description

suction cup ESS-30-CS easily interchangeable, Suction cup height compensator: 10,5 mm, Min. workpiece radius: 80 mm, Nominal size: 3 mm, suction cup diameter: 30 mm, suction cup volume: 9,47 cm3

Product Details

  • Suction cup diameter
    30 mm
  • Mounting position
    Any
  • Operating pressure
    0 bar ... 0.95 bar
  • Ambient temperature
    -30 °C ... 180 °C
  • Type of mounting
    Via vacuum connection
  • Vacuum connection
    M6
  • Suction cup material
    VMQ (silicone)
  • Min. workpiece radius
    80 mm
  • Connection position
    Top
  • Classification of suction cup holder
    Size 4
  • For use in the food industry
    See supplementary material information
  • Product weight
    12.2 g
  • Shore hardness
    50 +/- 5
  • Nominal width
    3 mm
  • Type code
    ESS
  • Suction cup shape
    Round bellows, 3.5 convolutions
  • Corrosion resistance class (CRC)
    1 - Low corrosion stress
  • Lateral force at nominal operating pressure
    11 N
  • Note on materials
    Free of copper and PTFE RoHS-compliant
  • Suction cup height compensation
    10.5 mm
  • Suction cup volume
    9.47 cm³
  • Symbol
    00991485
  • Nominal operating pressure
    -0.7 bar
  • Operating medium
    Atmospheric air based on ISO 8573-1:2010 [7:-:-]
  • Holding force at nominal operating pressure
    20.8 N
  • Color
    Transparent
  • Material of screwed trunnion
    Brass, nickel-plated Steel, galvanized and chrome-plated

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
