177691 Festo Pneumatic Components

177691 on Powermatic Associates
Festo

Part#:177691

Alt. Part#:CQL-12

Manufacturer:Festo

Category:Pneumatic Components

Product Lifecycle:Active

Product description

push-in L-connector CQL-12 For high flow rates. Nominal size: 8,65 mm, Assembly position: Any, Container size: 1, Design structure: Push/pull principle, Operating pressure complete temperature range: -0,95 - 7 bar

Product Details

  • Nominal width
    8.65 mm
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:-:-]
  • Product weight
    16 g
  • Housing material
    POM
  • Maritime classification
    See certificate
  • Pack size
    1
  • Design
    Push-pull principle
  • For use in the food industry
    See supplementary material information
  • Pneumatic connection 2
    for piping system/pneumatic tubing outside diameter of 12 mm
  • Releasing ring material
    POM
  • Operating pressure for entire temperature range
    -0.95 bar ... 7 bar
  • Corrosion resistance class (CRC)
    2 - Moderate corrosion stress
  • Ambient temperature
    -25 °C ... 70 °C
  • Type code
    CQL
  • Information on operating and pilot media
    Operation with oil lubrication possible (required for further use)
  • Material of tube retaining claw
    High-alloy stainless steel
  • Mounting position
    Any
  • Temperature-dependent operating pressure
    -0.95 bar ... 15 bar
  • Pneumatic connection 1
    For piping system/pneumatic tubing outside diameter of 12 mm
  • Note on materials
    Contains paint-wetting impairment substances RoHS-compliant

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

177691 Related Documents

177691 DataSheet.pdf
