164256 Festo Cable Assemblies

Product Details

• Contact durability
  100
• Electrical connection 1, connection type
  Socket
• Electrical connection for input 1, connection pattern
  00991871
• Electrical connection 2, number of pins/wires
  3
• Current rating at 40°C
  3 A
• Cable length
  5 m
• Nominal conductor cross section
  0.25 mm²
• Ambient temperature
  -25 °C ... 70 °C
• Color cable sheath
  Gray
• Conforms to standard
  Wire colors and connection numbers as per EN 60947-5-2 EN 61984
• Electrical connection 1, design
  Round
• Electrical connection 1, number of pins/wires
  3
• Electrical connection 2, function
  Control side
• DC operating voltage range
  0 V ... 60 V
• Cable characteristic
  Standard
• Bending radius, fixed cable installation
  ≥ 23 mm
• Cable diameter tolerance
  ± 0.1 mm
• Wire ends
  Cable end sleeve
• Storage temperature
  -25 °C ... 70 °C
• Material of cable sheath
  TPE-U(PUR)
Material of pin contacts
Brass, gold-plated
Cable designation
Without label holder
Electrical connection 1, connection technology
M8 snap-locking A-coded as per EN 61076-2-104
Electrical connection 2, occupied pins/wires
3
Connector cable test conditions
Flexural strength: as per Festo standard Cable chain: 5 million cycles, bending radius 28 mm
Degree of protection
IP65 IP67
Contamination level
3
Seals material
NBR
Type code
SIM
Electrical connection 1, function
Field device end
Electrical connection 1, cable outlet
Straight
Electrical connection 1, type of mounting
Snap-locking
Electrical connection 2, connection technology
Open end
Operating voltage range AC
0 V ... 60 V
Bending radius, flexible cable installation
≥ 46 mm
Cable design
3 x 0.25 mm²
Ambient temperature with flexible cable installation
-5 °C ... 70 °C
CE marking (see declaration of conformity)
As per EU low voltage directive
Housing colour
Black
Insulating sheath material
PP
Electrical connection 1, occupied pins/wires
3
Electrical connection 2, connection type
Cable
Surge resistance
1.5 kV
Cable diameter
4.5 mm
Note on degree of protection
In mounted state
Note on materials
Free of copper and PTFE Halogen-free
Corrosion resistance class (CRC)
4 - Particularly high corrosion stress
Housing material
TPE-U(PUR)
