161879 Festo Cable Assemblies

161879 on Powermatic Associates
Festo

Part#:161879

Alt. Part#:KMPPE-B-2,5

Manufacturer:Festo

Category:Cable Assemblies

Product Lifecycle:Active

Product description

plug socket with cable KMPPE-B-2,5 Pre-assembled, for proportional pressure regulators. Conforms to standard: DIN 47100, Cable identification: with accessories, Connection frequency: 500, Product weight: 243 g, Electrical connection 1, function: Field dev

Product Details

  • Electrical connection 1, function
    Field device end
  • Conforms to standard
    DIN 47100
  • Cable designation
    With accessories
  • Electrical connection 1, cable outlet
    Angled
  • Electrical connection 1, type of mounting
    Screw-type lock
  • Electrical connection 2, number of pins/wires
    8
  • Current rating at 40°C
    5 A
  • Contact durability
    500
  • Electrical connection 1, connection type
    Socket
  • Electrical connection 2, function
    Control side
  • Surge resistance
    0.6 kV
  • Cable diameter
    6.8 mm
  • Ambient temperature
    -30 °C ... 80 °C
  • Contamination level
    1
  • Type code
    KMPPE
  • Product weight
    243 g
  • Electrical connection 1, occupied pins/wires
    8
  • Electrical connection 2, connection type
    Cable
  • DC operating voltage range
    0 V ... 30 V
  • Connector cable test conditions
    Test conditions on request
  • Degree of protection
    IP67
  • Color cable sheath
    Gray
  • Material of screw-type lock
    PA
  • Electrical connection 1, design
    Round
  • Electrical connection 1, number of pins/wires
    8
  • Electrical connection 2, connection technology
    Open end
  • Cable length
    2.5 m
  • Cable design
    8 x 0.25 mm² Shielded
  • Note on degree of protection
    In mounted state
  • Note on materials
    RoHS-compliant
  • Electrical connection 1, connection technology
    M16x0.75 as per EN 61076-2-106
  • Electrical connection for input 1, connection pattern
    00995734
  • Electrical connection 2, occupied pins/wires
    8
  • Cable characteristic
    Standard
  • Wire ends
    Cut off bluntly
  • Ambient temperature with flexible cable installation
    -5 °C ... 70 °C
  • Nominal conductor cross section
    0.25 mm²
  • Material of cable sheath
    PVC
  • Housing material
    PA

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
