1544198 Festo Electrical Peripheral Devices

Product Details

• Dimensions W x L x H
  40 mm x 91 mm x 50 mm
• Power supply, function
  Electronics and load
• Power supply, number of pins/wires
  5
• Parameterization
  Activate diagnostics Fail-safe and idle response
• Protocol
  CC-LINK®
• CE marking (see declaration of conformity)
  As per EU EMC directive
• Product weight
  90 g
• LED display (product-specific)
  PS: operating voltage for electronics and load supply X2: module system status at I-Port 2
• Fieldbus interface, protocol
  CC-LINK®
• Fieldbus interface, function
  Bus connection, incoming/forwarding
• Fieldbus interface, galvanic isolation
  yes
• Fieldbus interface, connection technology
  Sub-D
• Fieldbus interface, number of poles/wires
  9
• Width dimension
  40 mm
• Internal cycle time
  1 ms per 1 byte of user data
• Intrinsic current consumption at nominal operating voltage
  Typ. 70 mA
• Corrosion resistance class (CRC)
  2 - Moderate corrosion stress
• Certification
  RCM compliance mark c UL us - Listed (OL)
• Housing material
  PA
• Type of mounting
  On electrical interface On electrical sub-base
KC characters
KC EMC
Power supply, type of connection
Plug
Power supply, connection pattern
00995383
Fieldbus interface, connection type
Socket
Diagnostics
Communication error Undervoltage
Type code
CTEU
Control elements
DIL switch
Nominal operating voltage DC
24 V
Degree of protection
IP65 IP67
LED display (bus-specific)
Err: data transmission error Run: bus active
Note on fieldbus interface
Optional connection technology with accessories: Open style (screw terminal, 5-pin, degree of protection: IP20)
Power supply, connection technology
M12x1, A-coded as per EN 61076-2-101
Fieldbus interface, transmission rate
156 - 10000 kbit/s
Note on degree of protection
In mounted state Unused connections sealed
Additional functions
System status can be indicated via process data
DC operating voltage range
18 V ... 30 V
Max. power supply
4 A
Storage temperature
-20 °C ... 70 °C
Max. address capacity outputs
16 byte
Note on materials
Contains paint-wetting impairment substances RoHS-compliant
Fieldbus interface, type
Serial interface
Fieldbus interface, connection pattern
00995638
Ambient temperature
-5 °C ... 50 °C
Max. address capacity inputs
16 byte

Related documents 1544198 Specs
