153238 Festo Pneumatic Fittings

153238 on Powermatic Associates
Festo

Part#:153238

Alt. Part#:QSLV4-3/8-10

Manufacturer:Festo

Category:Pneumatic Fittings

Product Lifecycle:Active

Product description

multiple distributor QSLV4-3/8-10 4-fold, 360° orientable. Size: Standard, Nominal size: 5,1 mm, Type of seal on screw-in stud: coating, Assembly position: Any, Design structure: Push/pull principle

Product Details

  • Nominal width
    5.1 mm
  • Temperature-dependent operating pressure
    -0.95 bar ... 14 bar
  • Pack size
    1
  • Pneumatic connection 1
    External thread R3/8
  • Releasing ring color
    Blue
  • Material of tube retaining claw
    High-alloy stainless steel
  • Maritime classification
    See certificate
  • Operating pressure for entire temperature range
    -0.95 bar ... 6 bar
  • Ambient temperature
    -10 °C ... 80 °C
  • No. of supply lines
    1
  • Material of tubing seal
    NBR
  • Type code
    QSLV4
  • Design
    Push-pull principle
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:-:-] Water as per manufacturer's declaration at www.festo.com
  • Pneumatic connection 2
    for pneumatic tubing outside diameter 10 mm
  • Note on materials
    RoHS-compliant
  • Size
    Standard
  • Mounting position
    Any
  • Information on operating and pilot media
    Operation with oil lubrication possible
  • No. of outlets
    4
  • Housing material
    PBT
  • Type of seal on screwed trunnion
    Coating
  • Corrosion resistance class (CRC)
    1 - Low corrosion stress
  • Product weight
    98 g
  • Releasing ring material
    POM

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
