1373812 Festo Vacuum Cups

Name: 1373812
Brand: Festo

Part#:1373812

Alt. Part#:VASB-55-1/4-SI-B

Manufacturer:Festo

Category:Vacuum Cups

Product Lifecycle:Active

Product description

suction cup VASB-55-1/4-SI-B Suction cup height compensator: 20 mm, Nominal size: 4 mm, suction cup diameter: 55 mm, suction cup volume: 30,4 cm3, Position of connection: on top

Product Details

Nominal operating pressure
-0.7 bar
Holding force at nominal operating pressure
110 N
Suction cup material
VMQ (silicone)
Suction cup volume
30.4 cm³
Mounting position
Any
Operating medium
Atmospheric air based on ISO 8573-1:2010 [7:-:-]
Vacuum connection
G1/4
Note on materials
Contains paint-wetting impairment substances RoHS-compliant
Suction cup diameter
55 mm
Symbol
00991485
Corrosion resistance class (CRC)
2 - Moderate corrosion stress
Type of mounting
Via vacuum connection
Material of screwed trunnion
Wrought aluminum alloy
Nominal width
4 mm
Type code
VASB
Operating pressure
-0.95 bar ... 0 bar
Ambient temperature
-40 °C ... 200 °C
Product weight
29 g
Color
Transparent
Suction cup height compensation
20 mm

Connection position

Top

Suction cup shape

Round bellows, 1.5 convolutions

For use in the food industry

See supplementary material information

Shore hardness

60 +/- 5

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
