WLB32ZC570PBQMG Banner Light Bars

WLB32ZC570PBQMG on Powermatic Associates
Banner

Part#:WLB32ZC570PBQMG

Manufacturer:Banner

Alt. Part#:89954

Product Lifecycle:Active

Get a quick Quote!

WLB32 Work Light Bar; Switched Hi/Low/Off; Length: 570 mm; Voltage: 90-264 V ac; Environmental Rating: IP50; Color: White; Cascadable; QD - Includes Type G Power cord; Diffuse window

About the manufacturer: Banner is one of the manufacturers that offers Light Bars that you can order at Powermatic Associates site. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.

Check out the WLB32ZC570PBQMG Banner price in the box on the right side or send a quick quote.

Product Details

  • Weight
    1315.4168 g
  • Country Of Origin
    MX
  • Feature: Quick Disconnect
    Yes
  • IO Link
    No
  • Modbus RTU
    No
  • Wireless
    No
  • Pro-Editor Compatible (Discrete)
    No
  • Feature: Chemical Resistant
    No
  • Feature: Cascade
    Yes
  • Feature: Audible
    No
  • Max Op. Temperature (°C)
    45
  • Illumination Switch Function
    I=Low; O=OFF; II=High
  • Primary Window Material
    Polycarbonate Diffused
  • Min Op. Temperature (°C)
    -25
  • Feature: Hazardous Area
    No
  • Illuminated Length (LxWxH mm)
    570.0
  • Physical Dimensions (LxWxH or DxH mm)
    580.0 x 32.0 x 46.0
  • Storage Temp (°C)
    -40 to 70
  • Environmental Rating
    IP50
  • Animation Option 1
    Solid On
  • Number of Input Pins/Conductors
    3
  • Dimming Option
    High-Low-Off
  • Supply Voltage
    90-264 V ac
  • Color 1 - Wavelength/Color Temp/Coordinates
    5000K (Daylight)
  • Lumens Color 1
    1500
  • Color Technology
    Standard LED
  • Color Option 1
    White
  • Connection
    Integral QD
  • Primary Housing Material
    Aluminum
  • Housing Style
    Linear Strip
  • Power
    AC
  • Product Size (mm)
    32
  • Power Source
    AC
  • Number of Colors / Segments
    1
  • Illumination
    Yes
  • Color Input Control
    Individual (One wire/color, same number of colors as input wires)
  • Mounting Thread
    No Thread

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

WLB32ZC570PBQMG Description

Banner Engineering WLB32ZC570PBQMG is a cascadable industrial LED workstation task light bar designed for a variety of settings. It features a high/low/off switch type G power cord and provides 1-color Daylight White (DW) LED illumination. This task light operates on a supply voltage range of 90Vac-264Vac, accommodating 120Vac, 220Vac, 230Vac, and 240Vac systems. It measures 570mm in length and 32mm in width, with a polycarbonate (PC) diffused window and an aluminium housing for durability. The light bar is pre-wired with a 1.8m / 5.9ft power cord, terminated with a plug compatible in the UK, Ireland, Cyprus, Malta, Malaysia, Singapore, Hong Kong, and Vietnam. Its linear shape is designed for easy integration into workspaces, and it offers a degree of protection rated at IP50. Suitable for operation in ambient air temperatures ranging from -25°C to +45°C, it includes 1 x digital input (100-240Vac) for color control. The current consumption is 250mA, and it provides a luminous flux of 1500 lumens.

Related documents WLB32ZC570PBQMG Specs

WLB32ZC570PBQMG 176314.pdf
