T30UDNAQ

Banner

Product Lifecycle: Active

Banner Engineering T30UDNAQ is a short-range ultrasonic level sensor from the T30U series, designed with a time-of-flight system and TEACH mode for pump control. This sensor features a thermoplastic housing and is pre-equipped with a 5-pin Euro-style M12 connector. It operates on a supply voltage of 12Vdc-24Vdc and can function within an ambient air temperature range of -20 to +70°C. The T30UDNAQ offers a degree of protection rated at IP67 NEMA 6P, making it suitable for challenging environments. Its shape is an M30 cylindrical threaded/barrel, and it includes 2 digital outputs (NPN transistor; complementary NO/NC) for connectivity. The sensing distance of this sensor ranges from 0.15cm to 1m, with a 228kHz transmission frequency. It also features protection functions against overload and short-circuit, and it has an M30 thread size for mounting.

T30UDNAQ

Banner Engineering T30UDNAQ is a short-range ultrasonic level sensor from the T30U series, designed with a time-of-flight system and TEACH mode for pump control. This sensor features a thermoplastic housing and is pre-equipped with a 5-pin Euro-style M12 connector. It operates on a supply voltage of 12Vdc-24Vdc and can function within an ambient air temperature range of -20 to +70°C. The T30UDNAQ offers a degree of protection rated at IP67 NEMA 6P, making it suitable for challenging environments. Its shape is an M30 cylindrical threaded/barrel, and it includes 2 digital outputs (NPN transistor; complementary NO/NC) for connectivity. The sensing distance of this sensor ranges from 0.15cm to 1m, with a 228kHz transmission frequency. It also features protection functions against overload and short-circuit, and it has an M30 thread size for mounting.

  • WirelessNo
  • ProfibusNo
  • 1-wire Serial InterfaceNo
  • RS-485No
  • SSINo
  • Application: UltrasonicYes
  • RS-232No
  • PROFINETNo
  • IO LinkNo
  • Feature: Clear Object DetectionYes
  • Feature: Chemical ResistantNo
  • Feature: Remote TeachYes
  • Feature: Timing (Hold/Delay)No
  • Ultrasonic Frequency (kHz)228
  • Max Off-state Leakage Current (µA)10
  • Supply Protection CircuitryProtected against reverse polarity and transient overvoltages
  • Power/Current Consumption (exclusive of load)90 mA
  • Max Operating Temperature (°C)70
  • Max Op. Relative Humidity Non-Condensing (%)100
  • Barrel Diameter (mm)30
  • VibrationMIL-STD-202F req. Method 201A (vibration:10 to 60Hz max., double amplitude 0.06", max acc. 10G).
  • RS-422No
  • Common Ethernet ProtocolNo
  • Discrete Output Hysteresis (mm)2.5
  • Remote Teach and Laser Control Input Impedence55 kΩ
  • Minimum Window Size (mm)10
  • Minimum Response Time (ms)48
  • Warm-up Time (minutes)15
  • Min Operating Temperature (°C)-20
  • NEMA RatingNEMA 6P
  • IP RatingIP67
  • Max Discrete (Switched) Output (mA)100
  • Output ProtectionProtected against false pulse on power-up and continuous overload or short-circuit of outputs
  • Discrete (Switched) Outputs2 NPN
  • Output Saturation Voltage NPN Outputs< 1.0 V at 10 mA ; < 1.5 V at 100 mA
  • Mechanical ShockIEC 60947-5-2 requirements: 30G 11 ms duration, half sine wave
  • Number of Pins5
  • Temperature Effect (mm/°C)0.2% of sensing distance/°C
  • AdjustmentsTeach Button
  • Minimum Sensing Distance (mm)150
  • Power Supply12-24 V dc
  • Max Sensing Distance (mm)1000
  • IndicatorLED(s)
  • Quick Disconnect TypeM12 (Euro)
  • Analog Resolution/Discrete Repeatability+/- 0.25% of measured distance (0.5 min)
  • ConnectionIntegral QD
  • Input/OutputDiscrete
  • Device TypeSensor
  • Sensing Mode (General)Proximity
  • PowerDC
  • Sensing Mode (Detailed)Time of Flight
  • Primary Housing MaterialPBT
  • Housing StyleBarrel
  • PC ConfigurableNo
  • Max Measurement Range>500 mm - <=1000 mm
  • Sensing BeamUltrasonic
  • ShapeCylindrical smooth
  • Protection functionsOverload Short-circuit
  • Emission frequency228kHz
  • Sub-range nameT30U series
  • Sensing distance0.15cm...1m
  • Digital outputs2 x digital outputs (NPN transistors)
  • Degree of protectionIP67 NEMA 6P
  • Main functionSensor (Liquid level)
  • Designtime-of-flight system
  • Mounting modeThreaded mount
  • Compliant with standard(s)CE
  • Primary brandBanner Engineering
  • Supply voltage (DC)12Vdc-24Vdc
  • Connection typePre-equipped with 5-pin Euro-style M12 connector
  • Ambient air temperature for operation-20...+70 °C
  • Product series / family nameU-GAGE series
  • FunctionsShort-range ultrasonic level sensor (for pmp. control) green LED (power ON) yellow LED (discrete output / mode) red LED (signal) TEACH mode
  • Thread sizeM30
  • Materialthermoplastic housing
  • Order code / Manufacturer SKU55548
