S18LGXRPQP Banner Signal Beacons

Name: S18LGXRPQP
Brand: Banner

Banner S18LGXRPQP S18 EZ-LIGHT - 18 mm - IP67; Two Color: Green Red; 10-30 V dc PNP Input; 150 mm (6 in) 4-pin M12 PVC Pigtail QD

Part#:S18LGXRPQP

Manufacturer:Banner

Alt. Part#:94762

Product Lifecycle:Active

Get a quick Quote!

S18 EZ-LIGHT - 18 mm - IP67; Two Color: Green Red; 10-30 V dc PNP Input; 150 mm (6 in) 4-pin M12 PVC Pigtail QD

About the manufacturer: Banner is one of the manufacturers that offers Signal Beacons that you can order at Powermatic Associates site. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.

Check out the S18LGXRPQP Banner price in the box on the right side or send a quick quote.

Product Details

Weight
45.2684816 g
Country Of Origin
CN
Pro-Editor Compatible (Discrete)
No
Wireless
No
Feature: Quick Disconnect
Yes
Modbus RTU
No
Feature: Chemical Resistant
No
Multi-Color Device
Single Color On
IO Link
No
Primary Housing Color
Black
Primary Window Material
Polycarbonate Diffused
Feature: Hazardous Area
No
Feature: Audible
No
Feature: Washdown Rated
Yes
Environmental Rating
IP67; IP69
Min Op. Temperature (°C)
-40
Max Op. Temperature (°C)
50
NEMA Type and UL Type Rating
NEMA and UL 4X, 13
Physical Dimensions (LxWxH or DxH mm)
23.5 x 35.7
Max Input Response Time (ms)
1

Number of Input Pins/Conductors

Input Type

PNP

Supply Voltage

10-30 V dc

Max Current Color (mA)

Color Option 3

Red

Color 3 - Wavelength/Color Temp/Coordinates

625 nm

Lumens Color 3

1.1

Quick Disconnect Type

M12 (Euro)

Lumens Color 1

4.1

Animation Option 1

Solid On

Color 1 - Wavelength/Color Temp/Coordinates

525 nm

Connection

Pigtail QD

Product Size (mm)

Color Technology

Standard LED

Number of Colors / Segments

Indication

Yes

Primary Housing Material

Polycarbonate

Color Option 1

Green

Housing Style

Barrel Mount - Flat Window

Power

Color Input Control

Individual (One wire/color, same number of colors as input wires)

Power Source

Mounting Thread

M18 x 1.0

Cable Length (m)

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

S18LGXRPQP Description

Banner Engineering S18LGXRPQP, part of the EZ-LIGHT series, is a pilot light designed with a 2-color G/R color pattern LED illumination. This LED pilot light indicator features a polycarbonate (PC) diffused window and base, with a diameter of 18mm. It is pre-wired with a 6" / 15cm pigtail that terminates with a 4-pin M12 Euro-style QD connector. The housing is black, and it operates on a supply voltage of 10Vdc-30Vdc (12Vdc-24Vdc nom.). The S18LGXRPQP is designed for flush mounting in an 18mm hole with an M18 thread. It can operate in ambient air temperatures ranging from -40°C to +50°C. This part offers a degree of protection rated at IP67, IP69K, NEMA 4X, NEMA 13, UL type 4X, and UL type 13. Its shape is characterized by a round protruding window and a threaded cylindrical barrel. The current consumption is 25mA, and it includes 2 x digital inputs (10-30Vdc; PNP) for color control.
