PIT21TS Banner Through Beam Sensors

PIT21TS on Powermatic Associates
Banner

Part#:PIT21TS

Alt. Part#:70380

Manufacturer:Banner

Category:Through Beam Sensors

Product Lifecycle:Active

Product description

Plastic Fiber, Opposed Mode; Core Dia.: 0.5 mm; Fiber Length 0.3 m; Thread; TS Termination

Product Details

  • Weight
    54.43104 g
  • Country Of Origin
    JP
  • Termination Type
    Plastic Fiber Sensors
  • Max Distance: DF-G3 (mm)
    No Data
  • Fiber Sensing End Size - Mounting Area
    M3
  • Max Distance: DF-G1 (mm)
    No Data
  • Max Distance: DF-G2 (mm)
    No Data
  • Tariff Fiber Meters (fbm)
    .61
  • Measured Max Distance (mm)
    No Data
  • Application: Vacuum Feed Through
    None
  • Application: Liquid Level
    No
  • Feature: Extended Range
    No
  • Feature: Small Object Detection
    No
  • Feature: Chemical Resistant
    No
  • Integrated Lens
    No
  • Minimum Repeat Bending Endurance
    5000
  • Max Temp ( °C)
    70
  • Termination
    Terminated
  • Minimum Bend Radius (mm)
    25
  • Core Diameter (mm)
    0.5
  • Retractile
    No
  • Sensing End Segment 2
    Thread
  • Flex Relief
    No
  • Sensing End Segment 1
    Ferrule
  • Fiber Sensing End Size
    M3
  • Sensing Mode (General)
    Opposed
  • Fiber Length (m)
    0.304
  • Beam Exit
    In-line
  • Quantity Included
    2
  • Fiber Sheathing Material (Jacket)
    Stainless Steel Monocoil
  • Fiber Sensing End Tip
    Thread
  • Sensing End Material (Specific)
    Stainless Steel
  • Sensing Mode (Detailed)
    Reflective
  • Fiber Optic Type
    Plastic
  • Housing Style
    Round

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of PIT21TS on Powermatic Associates is $134.00. Order now.

About the product

Banner Engineering PIT21TS is a fiber optic sensor designed for in-line sensing with a through-beam system or opposed mode pair of individual fibers. It operates effectively at an ambient air temperature up to +70°C. This sensor is part of the Plastic fiber series and features a cylindrical (threaded) probe tip with a diameter of 0.5mm for the fiber core. The sensing end is made of stainless steel, while the fiber itself is plastic, and it is protected by a stainless steel monocoil. The total length of the sensor is 3 feet or approximately 1 meter.

PIT21TS Related Documents

PIT2 SERIES TERMINATED-1630955152505.stpPIT2 SERIES TERMINATED-1630955152508.pdf
