PIF46UM.18F Banner Through Beam Sensors

PIF46UM.18F on Powermatic Associates
Banner

Part#:PIF46UM.18F

Alt. Part#:40424

Manufacturer:Banner

Category:Through Beam Sensors

Product Lifecycle:Active

Product description

Plastic Fiber, Opposed Mode; Core Dia.: 1 mm; Fiber Length 2 m; Ferrule; Free cut

Product Details

  • Weight
    36.28736 g
  • Country Of Origin
    JP
  • Max Distance: DF-G1 (mm)
    No Data
  • Max Distance: DF-G3 (mm)
    No Data
  • Fiber Sensing End Size - Mounting Area
    4.8 mm
  • Max Distance: DF-G2 (mm)
    No Data
  • Measured Max Distance (mm)
    No Data
  • Tariff Fiber Meters (fbm)
    4
  • Feature: Small Object Detection
    No
  • Termination Type
    Plastic Fiber Sensors
  • Application: Vacuum Feed Through
    None
  • Application: Liquid Level
    No
  • Feature: Extended Range
    No
  • Feature: Chemical Resistant
    No
  • Integrated Lens
    No
  • Minimum Repeat Bending Endurance
    10000
  • Max Temp ( °C)
    70
  • Termination
    Free Cut
  • Minimum Bend Radius (mm)
    25
  • Core Diameter (mm)
    1
  • Flex Relief
    No
  • Retractile
    No
  • Fiber Sensing End Size
    4.8 mm
  • Sensing End Segment 1
    Ferrule
  • Fiber Length (m)
    2
  • Fiber Sheathing Material (Jacket)
    Polyethylene
  • Fiber Sensing End Tip
    Ferrule
  • Sensing End Material (Specific)
    Stainless Steel
  • Beam Exit
    In-line
  • Fiber Optic Type
    Plastic
  • Sensing Mode (General)
    Opposed
  • Sensing Mode (Detailed)
    Reflective
  • Quantity Included
    2
  • Housing Style
    Round

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of PIF46UM.18F on Powermatic Associates is $85.00. Order now.

About the product

Banner Engineering PIF46UM.18F is a fiber optic sensor designed for through-beam system applications, featuring an opposed mode ferrule end tip pair of individual fibers for in-line sensing. This sensor operates effectively at an ambient air temperature up to +70°C. It is part of the Plastic fiber series, with a 1mm fiber core diameter and a 6ft (2m) length. The sensor's design includes a cylindrical (smooth) end tip, constructed from stainless steel for the sensing end, and utilizes plastic fiber with a polyethylene (PE) fiber sheath for durability and performance.

PIF46UM.18F Related Documents

PIF4 FERRULE DIA .18 UNTERMINATED-1630955107096.stpPIF4 FERRULE DIA .18 UNTERMINATED-1630955107090.pdf
