Powermatic Associates Logo

PBCT23T Banner Through Beam Sensors

PBCT23T on Powermatic Associates
Banner

Part#:PBCT23T

Manufacturer:Banner

Alt. Part#:39146

Product Lifecycle:Active

Get a quick Quote!

Plastic Fiber, Diffuse Reflective; Core Dia.: 0.5 mm & 9 x 0.25 mm; Fiber Length 1 m; Coaxial, Thread; T Termination

About the manufacturer: Banner is one of the manufacturers that offers Through Beam Sensors that you can order at Powermatic Associates site. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.

Check out the PBCT23T Banner price in the box on the right side or send a quick quote.

Product Details

  • Weight
    45.3592 g
  • Country Of Origin
    JP
  • Measured Max Distance (mm)
    No Data
  • Max Distance: DF-G1 (mm)
    No Data
  • Max Distance: DF-G2 (mm)
    No Data
  • Fiber Sensing End Size - Mounting Area
    M4
  • Max Distance: DF-G3 (mm)
    No Data
  • Tariff Fiber Meters (fbm)
    10
  • Termination Type
    Plastic Fiber Sensors
  • Application: Liquid Level
    No
  • Application: Vacuum Feed Through
    None
  • Feature: Small Object Detection
    No
  • Feature: Extended Range
    No
  • Feature: Chemical Resistant
    No
  • Minimum Repeat Bending Endurance
    5000
  • Integrated Lens
    No
  • Max Temp ( °C)
    70
  • Termination
    Terminated
  • Core Diameter (mm)
    0.5 & 9 x 0.3
  • Minimum Bend Radius (mm)
    10
  • Retractile
    No
  • Sensing End Segment 1
    Thread
  • Fiber Length (m)
    1
  • Flex Relief
    No
  • Fiber Sensing End Size
    M4
  • Sensing Mode (Detailed)
    Coaxial
  • Beam Exit
    In-line
  • Fiber Optic Type
    Plastic
  • Housing Style
    Round
  • Quantity Included
    1
  • Fiber Sensing End Tip
    Thread
  • Sensing End Material (Specific)
    Stainless Steel
  • Fiber Sheathing Material (Jacket)
    Polyethylene
  • Sensing Mode (General)
    Diffuse

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

PBCT23T Description

Banner Engineering PBCT23T is a fiber optic sensor designed for diffuse-reflective system applications with a bifurcated fiber in-line/coaxial sensing mechanism. It features a 0.5mm fiber core diameter and is part of the Plastic fiber series. The sensor has a cylindrical (threaded) end tip shape, ensuring compatibility with various installations. It is constructed with a stainless steel sensing end and a plastic fiber polyethylene (PE) fiber sheath for durability. The PBCT23T is designed to operate in ambient air temperatures up to +70°C and has a length of 3ft / 1m, accommodating a range of application needs.

Related documents PBCT23T Specs

PBCT23T PBCT2 SERIES TERMINATED-1630955004701.stp
PBCT23T PBCT2 SERIES TERMINATED-1630955004697.pdf
