LE550DQP

Banner

Product Lifecycle: Active

Banner Engineering LE550DQP is a Class 2 laser displacement sensor, part of the LE series, designed with a triangulation system and an LCD display for easy configuration through TEACH mode. It emits a visible class 2 red laser with a wavelength of 650 nm for displacement measurement. The sensor is housed in a rectangular, die-cast zinc alloy casing with an acrylic window, ensuring durability. It comes pre-wired with a 6" / 150mm pigtail that terminates with a 5-pin Euro-style M12 connector for easy installation. The LE550DQP operates on a supply voltage of 12Vdc to 30Vdc, with 24Vdc nominal, and can function within an ambient air temperature range of -20 to +55 °C. It offers a sensing distance from 10cm to 1m and includes two digital outputs (PNP/NPN transistor) for versatile connectivity. Protection features include overload and short-circuit prevention. This sensor is rated with an IP67 and NEMA 6 degree of protection, signifying its robustness against dust and water ingress.

LE550DQP

Banner Engineering LE550DQP is a Class 2 laser displacement sensor, part of the LE series, designed with a triangulation system and an LCD display for easy configuration through TEACH mode. It emits a visible class 2 red laser with a wavelength of 650 nm for displacement measurement. The sensor is housed in a rectangular, die-cast zinc alloy casing with an acrylic window, ensuring durability. It comes pre-wired with a 6" / 150mm pigtail that terminates with a 5-pin Euro-style M12 connector for easy installation. The LE550DQP operates on a supply voltage of 12Vdc to 30Vdc, with 24Vdc nominal, and can function within an ambient air temperature range of -20 to +55 °C. It offers a sensing distance from 10cm to 1m and includes two digital outputs (PNP/NPN transistor) for versatile connectivity. Protection features include overload and short-circuit prevention. This sensor is rated with an IP67 and NEMA 6 degree of protection, signifying its robustness against dust and water ingress.

L-GAGE LE SERIES CABLE/PIGTAIL.pdf

L-GAGE LE SERIES CABLE/PIGTAIL.stp

Product details

L-GAGE LE SERIES CABLE/PIGTAIL.pdf

L-GAGE LE SERIES CABLE/PIGTAIL.stp

SSINo
ProfibusNo
1-wire Serial InterfaceNo
WirelessNo
RS-485No
RS-422No

RS-232No

Common Ethernet ProtocolNo

PROFINETNo

IO LinkNo

Feature: Health/ Marginal Signal OutputYes

Feature: Chemical ResistantNo

Feature: Timing (Hold/Delay)Yes

Feature: Remote TeachYes

Supply Protection CircuitryProtected against reverse polarity and transient overvoltages

Power/Current Consumption (exclusive of load)70 mA @ 24 V dc

Max Off-state Leakage Current (µA)NPN: < 200 at 30 V dc; PNP: < 10 at 30 V dc

Max Ambient Light (Lux)10000

Alarm Output (mA)100

Laser ControlYes

Discrete Output Hysteresis (mm)Automatically adjusted

Minimum Window Size (mm)10

Spot Size (@ Reference Distance)4.9 mm x 12.1 mm @ 1 m

Minimum Response Time (ms)2

Warm-up Time (minutes)10

Max Operating Temperature (°C)55

Window MaterialAcrylic

Max Op. Relative Humidity Non-Condensing (%)90 at 55°C

Min Operating Temperature (°C)-20

Storage Temperature (°C)-30 to 65

Discrete (Switched) Outputs2 NPN/PNP Configurable

NEMA RatingNEMA 6

Max Discrete (Switched) Output (mA)100

Output ProtectionProtected against continuous overload and short circuit

IP RatingIP67

Output Saturation Voltage PNP Outputs< 3 V at 100 mA

Output Saturation Voltage NPN Outputs< 1.6 V at 100 mA

Mechanical ShockIEC 60947-5-2 requirements: 30G 11 ms duration, half sine wave

AdjustmentsPush Button; Remote Teach

VibrationMIL-STD-202G req. Method 201A (vibration:10 to 60Hz max., double amplitude 0.06", max acc. 10G).

Number of Pins5

Sensing Beam Wavelength (nm)650

Temperature Effect (mm/°C)+/- 0.25 mm/°C from 100 to 600 mm, +/- 0.5 mm/°C at 1000 mm

Delay at Power-up (ms)2000

Power Supply12-30 V dc

Minimum Sensing Distance (mm)100

Max Sensing Distance (mm)1000

ConnectionPigtail QD

IndicatorLCD; LED(s)

Quick Disconnect TypeM12 (Euro)

Analog Resolution/Discrete Repeatability100 mm to 600 mm: < 0.5; 600 mm to 1000 mm: < 1

Input/OutputDiscrete

Laser ClassificationClass 2

PowerDC

Primary Housing MaterialZinc Alloy Die-Cast

Cable Length (m)0.15

PC ConfigurableNo

Sensing Mode (Detailed)Triangulation

Sensing Mode (General)Proximity

Device TypeSensor

Sensing BeamVisible Red Laser

Housing StyleRectangular

Max Measurement Range>500 mm - <=1000 mm
