K90FDLBPQ Banner Signal Beacons
Part#:K90FDLBPQ
Alt. Part#:96140
Manufacturer:Banner
Category:Signal Beacons
Product Lifecycle:Active
Product description
K90F Series EZ-LIGHT; 1-Color Daylight Visible Indicator; Voltage: 12-30 V dc; Environmental Rating: IP67; Input: PNP; Colors: Blue; 5-pin M12 Integral QD
Product Details
- Weight 217.72416 g
- Country Of Origin MX
- Max Current Color (mA) 475
- Number of Colors / Segments 1
- Cable Length (m) 0.15
- Pro-Editor Compatible (Discrete) No
- Wireless No
- Modbus RTU No
- IO Link No
- Feature: Quick Disconnect Yes
- Indication Intensity High Brightness & Daylight Visible
- Feature: Chemical Resistant No
- Feature: Hazardous Area No
- Feature: Audible No
- Primary Window Material Polycarbonate Clear
- Min Op. Temperature (°C) -40
- Max Op. Temperature (°C) 50
- NEMA Type and UL Type Rating NEMA 4X, 13
- Input Type PNP
- Max Input Response Time (ms) 75
- Physical Dimensions (LxWxH or DxH mm) 90.0 x 42.0
- Environmental Rating IP67
- Supply Voltage 12-30 V dc
- Wire Selectable Function Flashing
- Number of Input Pins/Conductors 5
- Lumens Color 1 55.0
- Color Option 1 Blue
- Connection Integral QD
- Color 1 - Wavelength/Color Temp/Coordinates 470 nm
- Color Technology Standard LED
- Product Size (mm) 90
- Quick Disconnect Type M12 (Euro)
- Animation Option 1 Solid On
- Indication Yes
- Color Input Control Individual (One wire/color, same number of colors as input wires)
- Mounting Thread M30 x 1.5
- Primary Housing Material Polycarbonate
- Power Source DC
- Housing Style Base Mount - Flat Window
- Power DC
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of K90FDLBPQ on Powermatic Associates is $143.00. Order now.
About the product
Banner Engineering K90FDLBPQ is a pilot light from the EZ-LIGHT series designed with a flat LED pilot light indicator featuring flashing input control. It showcases daylight-visible 3-color B/Y/W (Blue/Yellow/White) LED illumination within a black housing. The round flat window shape is constructed from clear Polycarbonate (PC) for both the window and the base. This unit is pre-wired with a 2m / 6.5ft 5-wire cable terminated with bare end flying leads for connectivity. It operates on a supply voltage range of 12Vdc to 30Vdc, with 24Vdc nominal. The K90FDLBPQ offers versatile mounting options including surface, base, or pole flush with a 30mm hole and M30 thread, and has a 90mm diameter light area. It is designed to operate within an ambient air temperature range of -40°C to +50°C. This pilot light is protected to IP67, NEMA 4X, and NEMA 13 standards, ensuring durability in various environments. It has a current consumption of 475mA and includes 3 x digital inputs (12-30Vdc; PNP) for color control.
