AC/DC Power Supplies
AC/DC power supplies are power supplies that convert alternating current from the grid into direct current that is needed to power most electronics. AC/DC power supplies are integral components in systems that make the world go round.
PULS QT40.361 is a power supply unit designed for AC/DC conversion with a 50% power reserve. It features DIN rail mounting and operates within an ambient air temperature range of -25 to +70°C. The unit is equipped with a DC-OK relay contact output and offers a rated current of 26.7A at 36Vdc and 22.9A at 42Vdc, with a power derating of 24W at temperatures from +60°C to +70°C. Connection is facilitated through screw-clamp connections. The supply voltage accommodates a wide range of 323Vac to 576Vac (with nominal values including 380Vac, 400Vac, 415Vac, 440Vac, 480Vac, 500Vac, and 525Vac; 47-63Hz), featuring a 3-phase input, a turn-ON voltage of 3 x 305Vac, and a shutdown voltage of 3 x 275Vac in steady-state conditions. This part of the Q-series measures W110mm x H124mm x D127mm and is housed in aluminium. It is designed for a 3-phase network, with a net width of 110 mm. The rated power is 960W at both 36Vdc and 42Vdc, with a short-term capacity of 1440W for up to 4 seconds. The output voltage is adjustable between 36Vdc and 42Vdc, with a turn-ON overshoot of 750mV. Protection functions include output overvoltage protection, active input inrush current limiter, and overload/short-circuit protection. It supports series or parallel operation for increased output power and is resistant to back-feeding loads up to 50V. The efficiency rates are 0.952 at 3x480Vac input and 0.953 at 3x400Vac input. Peak inrush current consumption is 6A at both 3x400Vac and 3x480Vac inputs. The unit has a start-up delay of 500-600s, with rise times of 40ms and 45ms under specified conditions, and a hold time of 25ms. Power dissipation losses are 48.4W and 47.3W for 3x480Vac and 3x400Vac inputs, respectively, under full output load. Electrical durability spans from 363000 hours to 72000 hours across various conditions, with a ripple of 130mVpp at 20Hz to 20MHz and an output stage capacitance of 4700µF.
Quick Quote
PULS SLA4.100 is a power supply unit designed with a PFC compliant to EN 61000-3-2 standards, featuring a DC-OK relay contact output. It serves as an AS-Interface power supply unit (PSU) encased in a robust metal housing. This unit offers screw-clamp connections for secure installation and measures W73mm x H124mm x D102mm. It supports a wide range of supply voltages, including AC inputs from 85Vac-132Vac / 187Vac-264Vac across various nominal values and a DC input range of 240Vdc-300Vdc, with a rated current of 4A at 30.5Vdc. Designed for DIN rail mounting, it operates efficiently within an ambient air temperature range of -10...+70 °C. The SLA4.100 experiences a peak inrush current consumption of 49.7A at 230Vac input and 44.7A at 120Vac input, suitable for single-phase (1AC) or DC networks. It incorporates multiple protection functions, including output overvoltage protection up to 55Vdc max., NTC for input inrush current limiting, and overload/short-circuit protection with a current range of min. 4.2A to max. 6.5A, though it does not support series or parallel operation or ground-fault monitoring. The output voltage is fixed at 30.5Vdc, with an efficiency of 0.9 at 230Vac input, a hold time of 30ms at 100Vac input, power dissipation/losses at 13.5 W under full output load at 230Vac input, and a ripple of 50mVpp across 20Hz to 20MHz at 50Ω.
Quick Quote
PULS XT40.362 is a power supply unit part of the X-series, designed to convert AC to DC power with a semi-regulated 25% power reserve. It features a DC-OK relay contact output and operates on a supply voltage of 3x432-528Vac (440Vac / 480Vac / 500Vac / 525Vac nominal; 47-63Hz), with a turn-on voltage of 3 x 390Vac and a shutdown voltage of 3 x 355Vac. The unit is housed in an aluminium casing, measures W96mm x H124mm x D159mm, and uses screw-clamp connections for installation. It is rated for a current of 26.6A at 36Vdc and is designed for DIN rail mounting in a 3-phase (3AC) network. The ambient air temperature for operation ranges from -25 to +70°C. The XT40.362 has a peak inrush current consumption of 4A (at 3x480Vac input), a rated power of 960W at 36 Vdc (1200W for typ. 15s with derating applicable from +60°C to +70°C), and includes protection functions such as output overvoltage protection (42.5Vdc max.), active input inrush current limiter, and overload/short-circuit current protection. It is not suitable for parallel operation to increase output power but supports 1+1 redundancy for higher system availability. The unit is resistant to back-feeding loads up to 41.1V, has an efficiency of 0.955 (at 3x480Vac input), a start-up delay of 350ms, and a rise time of 40ms (70ms with 27mF load capacitance) at nominal input. The fixed output voltage is 36Vdc with a 700mV turn-ON overshoot, a hold time of 2.6ms at 3x480Vdc input, and power dissipation/losses of 45.2W at full output load. Its electrical durability is rated at 55000 hours (at 40°C; 26.6A output; 3AC 480Vdc input), with higher durability at reduced loads or temperatures. The output stage capacitance is 11100µF, and the ripple is 2000mVpp (20Hz...2KHz; 50Ω).
Quick Quote
PULS ML100.109 is a power supply unit (PSU) / converter designed for AC/DC applications with DIN rail mounting. It operates within an ambient air temperature range of -10 to +70°C and features a conformal coating design for enhanced durability. This unit provides a rated current of 4.2A at 24Vdc and utilizes spring-clamp connections for secure attachment. It supports a wide range of supply voltages from 85Vac-132Vac / 184Vac-264Vac (auto select) for AC and 213Vdc-348Vdc for DC, accommodating various network configurations including single-phase (1AC) or DC. The ML100.109 measures 73mm in width, 75mm in height, and 103mm in depth, housed in a PC / ABS blend for robustness. It delivers a rated power of 100W with an adjustable output voltage range of 24Vdc-28Vdc. Protection is provided by an NTC (input inrush current limiter), ensuring stability. The unit boasts an efficiency of 0.9 at 230Vac input, with a maximum inrush current consumption of 22A at 120Vac input and 37A peak at 230Vac input. Power dissipation is calculated at 11.4 W, and the ripple is maintained at 50mVpp across a frequency range of 20Hz to 20MHz at 50Ω.
Quick Quote
PULS QS40.484 is a power supply unit designed for DIN rail mounting, featuring AC/DC conversion with a 50% power reserve. It operates within an ambient air temperature range of -25 to +70°C and offers a design that includes a DC-OK relay contact output. The unit provides a rated current of 20A at 48Vdc and 17.8A at 54Vdc, with a power derating applicable from 24W at +60°C to +70°C. Connection is facilitated through screw-clamp connections, and it supports a supply voltage range of 180Vac to 264Vac, accommodating various nominal voltages within this range at a frequency of 47-63Hz. The QS40.484, part of the Q-series, measures 125mm in width, 124mm in height, and 127mm in depth, housed in an aluminium casing. It is designed for single-phase network operation and delivers a rated power of 960W, with a short-term capacity of 1440W for up to 4 seconds. The output voltage is adjustable between 48Vdc and 54Vdc. Protection features include output overvoltage protection and overload/short-circuit protection, with capabilities for series or parallel operation to increase output power. Efficiency is rated at 0.95 with a 230Vac input, and the unit exhibits a peak current consumption of 18A. Start-up and rise times are specified as 750ms and 18-35ms respectively, with a hold time of 30ms at 230Vac input. Power dissipation losses are detailed for both 230Vac and 120Vac inputs, and the electrical durability spans from 65,000 to 345,000 hours under various conditions. Ripple is maintained at 150mVpp across a 20Hz to 20MHz range, with an output stage capacitance of 3700µF.
Quick Quote
PULS QT20.361 is a power supply unit designed for DIN rail mounting, featuring AC/DC conversion with a 50% power reserve. It operates within an ambient air temperature range of -25 to +70°C and offers a design that includes a DC-OK relay contact output. The unit provides a rated current of 13.3A at 36Vdc and 11.4A at 42Vdc, with a power derating from 12W at +60°C to +70°C. Connection is facilitated through spring-clamp connections. It supports a wide supply voltage range of 323Vac to 576Vac across various nominal voltages (380Vac to 525Vac) at 47-63Hz, with a 3-phase input. The QT20.361, part of the Q-series, measures 65mm in width, 124mm in height, and 127mm in depth, housed in aluminium. It is designed for a 3-phase network, with a rated power of 480W at 36Vdc and 42Vdc, and can momentarily support up to 720W for 4 seconds. The output voltage is adjustable between 36Vdc and 42Vdc, with protection functions including output overvoltage protection and active input inrush current limiting. It allows for series or parallel operation for increased output power and is resistant to back-feeding loads up to 48V. The unit boasts an efficiency of up to 0.948, with a peak current consumption of 10A at inrush. It features a start-up delay of 290-350ms, a rise time of 30-40ms depending on load capacitance, and a hold time of 22ms. Power dissipation is 27.4W at full output load with a 3x480Vac input and 26.3W with a 3x400Vac input. Its electrical durability ranges from 48,000 to 250,000 hours, depending on operating conditions, with a ripple of 100mVpp and an output stage capacitance of 500µF.
Quick Quote
PULS PIM36.241 is a power supply unit designed for DIN rail mounting, featuring AC/DC conversion capabilities. It operates within an ambient air temperature range of -10 to +60°C with linear derating up to +70°C. The unit is equipped with a NEC Class 2 DC-OK relay contact output and provides a rated current of 5A at 12Vdc within the -10 to +60°C range and 3.8A at 12Vdc at +70°C. Connection is facilitated through push-in spring connections. The supply voltage (AC) spans from 90Vac to 264Vac for nominal inputs like 100Vac, 110Vac, 120Vac, 200Vac, 208Vac, 220Vac, 230Vac, and 240Vac at a frequency of 47-63Hz, with an input overvoltage tolerance of 264-300Vac for up to 500ms, a turn-ON voltage of 75Vac, and a shutdown voltage of 54Vac. This part of the PIM-series measures W36mm x H90mm x D91mm, has an IP20 degree of protection, and is housed in polycarbonate (PC). It supports a single-phase (1AC) network, has a net width of 36mm, and offers a rated power of 60W at -10 to +60°C, which derates linearly to 45.6W at +70°C. The output voltage (DC) is adjustable between 12Vdc and 15Vdc, with protection functions including output overvoltage protection and overload/short-circuit protection. Efficiency rates are 0.907 at 230Vac input and 0.902 at 120Vac input. Current consumption is 0.6A at 230Vac input (full output), 1A at 120Vac input (full output), and 1.15A at 100Vac input (full output), with a peak inrush of 44A at 230Vac input and 18A at 120Vac input. The unit has a start-up delay of 50-60ms, a rise time of 18ms max at nominal input with full constant current load and 0mF load capacitance, and a hold time of 107ms at 230Vac input. Power dissipation/losses are 6.2W at 230Vac input and 6.5W at 120Vac input under full output load. Electrical durability is noted at various conditions, with the highest being 724000 hours at 25°C, 2.5A, 1AC 230Vac input. Ripple is specified at 100mVpp (20Hz...20MHz; 50Ω), and the output stage capacitance is 2200µF.
Quick Quote
PULS CT10.481 is a power supply unit designed for DIN rail mounting, featuring an aluminium housing. It operates within an ambient air temperature range of -25 to +70°C and has a net width of 62mm. The unit consumes 0.6A with a 3 x 480Vac input and 0.7A with a 3 x 400Vac input, both at full 48Vdc output, with a peak inrush current of 10A. It boasts an efficiency of 0.929 for 3x480Vac input and 0.928 for 3x400Vac input. The dimensions are W62mm x H124mm x D117mm. It includes a 90ms start-up delay, a 55ms rise time at nominal input with a constant full current load and 0mF load capacitance, and a 140ms rise time with 5mF load capacitance. The unit features output overvoltage protection, an active input inrush current limiter, and supports series/parallel operation for increased output power. It is resistant to back-feeding loads up to 63V. Power dissipation/losses are 18.3W for 3x480Vac input and 18.6W for 3x400Vac input at full output load. The output stage capacitance is 2400µF. Electrical durability ranges from 78,000 to 704,000 hours depending on the operating conditions. The ripple is 100mVpp (20Hz...20MHz; 50Ω). This AC/DC power supply unit/converter offers a 20% power reserve and includes a DC-OK relay contact output. It features screw-clamp connections and supports a supply voltage of 323Vac-576Vac (wide range; 3-phase input) with a rated current of 6A at 48Vdc from -25 to +45°C and 3.75A at 48Vdc from -25 to +70°C. The output voltage is adjustable between 48Vdc and 56Vdc, with a hold time of 54ms at 3x480Vac input and 34ms at 3x400Vac input.
Quick Quote
PULS CP10.122 is a DIN rail mounting power supply unit enclosed in an aluminium housing, designed for an ambient air temperature range of -25 to +70°C. It features a net width of 39mm and dimensions of W39mm x H124mm x D117mm. The unit has a current consumption of 11A peak max. inrush at 230Vac input and 7A peak max. inrush at 120Vac input. Its efficiency rates are 0.943 at 230Vac input, 0.928 at 120Vac input, and 0.921 at 100Vac input. The CP10.122 offers a start-up delay of 240-300ms for 100-230Vac input, with rise times of 18ms and 35ms under specified conditions. It includes protection functions such as output overvoltage protection and overload/short-circuit current protection, with capabilities for series/parallel operation and resistance to back-feeding loads up to 25V. Power dissipation/losses are 11.6W at 230Vac input and 14.9W at 120Vac input, with an output stage capacitance of 5350µF. The electrical durability varies with conditions, reaching up to 534000 hours. The ripple is specified at 50mVpp (20Hz...20MHz; 50Ω). This AC/DC power supply unit, part of the CP-series, features a 20% power reserve, shutdown input, extended DC input, and DC-OK relay contact output, with screw-clamp connections. It supports a supply voltage range of 88Vdc-180Vdc and 85Vac-264Vac, with a rated current of 16A at 12Vdc, and offers a rated power of 192W. The output voltage is adjustable between 12Vdc and 15Vdc, with a 200mV turn-ON overshoot and a hold time of 50ms. It is suitable for single-phase (1AC) or DC networks.
Quick Quote
| Item | Manufacturer | Price | Stock | Delivery | |
|---|---|---|---|---|---|
| QT40.361 PULS QT40.361 is a power supply unit designed for AC/DC conversion with a 50% power reserve. It features DIN rail mounting and operates within an ambient air temperature range of -25 to +70°C. The unit is equipped with a DC-OK relay contact output and offers a rated current of 26.7A at 36Vdc and 22.9A at 42Vdc, with a power derating of 24W at temperatures from +60°C to +70°C. Connection is facilitated through screw-clamp connections. The supply voltage accommodates a wide range of 323Vac to 576Vac (with nominal values including 380Vac, 400Vac, 415Vac, 440Vac, 480Vac, 500Vac, and 525Vac; 47-63Hz), featuring a 3-phase input, a turn-ON voltage of 3 x 305Vac, and a shutdown voltage of 3 x 275Vac in steady-state conditions. This part of the Q-series measures W110mm x H124mm x D127mm and is housed in aluminium. It is designed for a 3-phase network, with a net width of 110 mm. The rated power is 960W at both 36Vdc and 42Vdc, with a short-term capacity of 1440W for up to 4 seconds. The output voltage is adjustable between 36Vdc and 42Vdc, with a turn-ON overshoot of 750mV. Protection functions include output overvoltage protection, active input inrush current limiter, and overload/short-circuit protection. It supports series or parallel operation for increased output power and is resistant to back-feeding loads up to 50V. The efficiency rates are 0.952 at 3x480Vac input and 0.953 at 3x400Vac input. Peak inrush current consumption is 6A at both 3x400Vac and 3x480Vac inputs. The unit has a start-up delay of 500-600s, with rise times of 40ms and 45ms under specified conditions, and a hold time of 25ms. Power dissipation losses are 48.4W and 47.3W for 3x480Vac and 3x400Vac inputs, respectively, under full output load. Electrical durability spans from 363000 hours to 72000 hours across various conditions, with a ripple of 130mVpp at 20Hz to 20MHz and an output stage capacitance of 4700µF. | Puls | Quick Quote | ||
| SLA4.100 PULS SLA4.100 is a power supply unit designed with a PFC compliant to EN 61000-3-2 standards, featuring a DC-OK relay contact output. It serves as an AS-Interface power supply unit (PSU) encased in a robust metal housing. This unit offers screw-clamp connections for secure installation and measures W73mm x H124mm x D102mm. It supports a wide range of supply voltages, including AC inputs from 85Vac-132Vac / 187Vac-264Vac across various nominal values and a DC input range of 240Vdc-300Vdc, with a rated current of 4A at 30.5Vdc. Designed for DIN rail mounting, it operates efficiently within an ambient air temperature range of -10...+70 °C. The SLA4.100 experiences a peak inrush current consumption of 49.7A at 230Vac input and 44.7A at 120Vac input, suitable for single-phase (1AC) or DC networks. It incorporates multiple protection functions, including output overvoltage protection up to 55Vdc max., NTC for input inrush current limiting, and overload/short-circuit protection with a current range of min. 4.2A to max. 6.5A, though it does not support series or parallel operation or ground-fault monitoring. The output voltage is fixed at 30.5Vdc, with an efficiency of 0.9 at 230Vac input, a hold time of 30ms at 100Vac input, power dissipation/losses at 13.5 W under full output load at 230Vac input, and a ripple of 50mVpp across 20Hz to 20MHz at 50Ω. | Puls | Quick Quote | ||
| XT40.362 PULS XT40.362 is a power supply unit part of the X-series, designed to convert AC to DC power with a semi-regulated 25% power reserve. It features a DC-OK relay contact output and operates on a supply voltage of 3x432-528Vac (440Vac / 480Vac / 500Vac / 525Vac nominal; 47-63Hz), with a turn-on voltage of 3 x 390Vac and a shutdown voltage of 3 x 355Vac. The unit is housed in an aluminium casing, measures W96mm x H124mm x D159mm, and uses screw-clamp connections for installation. It is rated for a current of 26.6A at 36Vdc and is designed for DIN rail mounting in a 3-phase (3AC) network. The ambient air temperature for operation ranges from -25 to +70°C. The XT40.362 has a peak inrush current consumption of 4A (at 3x480Vac input), a rated power of 960W at 36 Vdc (1200W for typ. 15s with derating applicable from +60°C to +70°C), and includes protection functions such as output overvoltage protection (42.5Vdc max.), active input inrush current limiter, and overload/short-circuit current protection. It is not suitable for parallel operation to increase output power but supports 1+1 redundancy for higher system availability. The unit is resistant to back-feeding loads up to 41.1V, has an efficiency of 0.955 (at 3x480Vac input), a start-up delay of 350ms, and a rise time of 40ms (70ms with 27mF load capacitance) at nominal input. The fixed output voltage is 36Vdc with a 700mV turn-ON overshoot, a hold time of 2.6ms at 3x480Vdc input, and power dissipation/losses of 45.2W at full output load. Its electrical durability is rated at 55000 hours (at 40°C; 26.6A output; 3AC 480Vdc input), with higher durability at reduced loads or temperatures. The output stage capacitance is 11100µF, and the ripple is 2000mVpp (20Hz...2KHz; 50Ω). | Puls | Quick Quote | ||
| ML100.109 PULS ML100.109 is a power supply unit (PSU) / converter designed for AC/DC applications with DIN rail mounting. It operates within an ambient air temperature range of -10 to +70°C and features a conformal coating design for enhanced durability. This unit provides a rated current of 4.2A at 24Vdc and utilizes spring-clamp connections for secure attachment. It supports a wide range of supply voltages from 85Vac-132Vac / 184Vac-264Vac (auto select) for AC and 213Vdc-348Vdc for DC, accommodating various network configurations including single-phase (1AC) or DC. The ML100.109 measures 73mm in width, 75mm in height, and 103mm in depth, housed in a PC / ABS blend for robustness. It delivers a rated power of 100W with an adjustable output voltage range of 24Vdc-28Vdc. Protection is provided by an NTC (input inrush current limiter), ensuring stability. The unit boasts an efficiency of 0.9 at 230Vac input, with a maximum inrush current consumption of 22A at 120Vac input and 37A peak at 230Vac input. Power dissipation is calculated at 11.4 W, and the ripple is maintained at 50mVpp across a frequency range of 20Hz to 20MHz at 50Ω. | Puls | Quick Quote | ||
| QS40.484 PULS QS40.484 is a power supply unit designed for DIN rail mounting, featuring AC/DC conversion with a 50% power reserve. It operates within an ambient air temperature range of -25 to +70°C and offers a design that includes a DC-OK relay contact output. The unit provides a rated current of 20A at 48Vdc and 17.8A at 54Vdc, with a power derating applicable from 24W at +60°C to +70°C. Connection is facilitated through screw-clamp connections, and it supports a supply voltage range of 180Vac to 264Vac, accommodating various nominal voltages within this range at a frequency of 47-63Hz. The QS40.484, part of the Q-series, measures 125mm in width, 124mm in height, and 127mm in depth, housed in an aluminium casing. It is designed for single-phase network operation and delivers a rated power of 960W, with a short-term capacity of 1440W for up to 4 seconds. The output voltage is adjustable between 48Vdc and 54Vdc. Protection features include output overvoltage protection and overload/short-circuit protection, with capabilities for series or parallel operation to increase output power. Efficiency is rated at 0.95 with a 230Vac input, and the unit exhibits a peak current consumption of 18A. Start-up and rise times are specified as 750ms and 18-35ms respectively, with a hold time of 30ms at 230Vac input. Power dissipation losses are detailed for both 230Vac and 120Vac inputs, and the electrical durability spans from 65,000 to 345,000 hours under various conditions. Ripple is maintained at 150mVpp across a 20Hz to 20MHz range, with an output stage capacitance of 3700µF. | Puls | Quick Quote | ||
| QT20.361 PULS QT20.361 is a power supply unit designed for DIN rail mounting, featuring AC/DC conversion with a 50% power reserve. It operates within an ambient air temperature range of -25 to +70°C and offers a design that includes a DC-OK relay contact output. The unit provides a rated current of 13.3A at 36Vdc and 11.4A at 42Vdc, with a power derating from 12W at +60°C to +70°C. Connection is facilitated through spring-clamp connections. It supports a wide supply voltage range of 323Vac to 576Vac across various nominal voltages (380Vac to 525Vac) at 47-63Hz, with a 3-phase input. The QT20.361, part of the Q-series, measures 65mm in width, 124mm in height, and 127mm in depth, housed in aluminium. It is designed for a 3-phase network, with a rated power of 480W at 36Vdc and 42Vdc, and can momentarily support up to 720W for 4 seconds. The output voltage is adjustable between 36Vdc and 42Vdc, with protection functions including output overvoltage protection and active input inrush current limiting. It allows for series or parallel operation for increased output power and is resistant to back-feeding loads up to 48V. The unit boasts an efficiency of up to 0.948, with a peak current consumption of 10A at inrush. It features a start-up delay of 290-350ms, a rise time of 30-40ms depending on load capacitance, and a hold time of 22ms. Power dissipation is 27.4W at full output load with a 3x480Vac input and 26.3W with a 3x400Vac input. Its electrical durability ranges from 48,000 to 250,000 hours, depending on operating conditions, with a ripple of 100mVpp and an output stage capacitance of 500µF. | Puls | Quick Quote | ||
| PIM36.241 PULS PIM36.241 is a power supply unit designed for DIN rail mounting, featuring AC/DC conversion capabilities. It operates within an ambient air temperature range of -10 to +60°C with linear derating up to +70°C. The unit is equipped with a NEC Class 2 DC-OK relay contact output and provides a rated current of 5A at 12Vdc within the -10 to +60°C range and 3.8A at 12Vdc at +70°C. Connection is facilitated through push-in spring connections. The supply voltage (AC) spans from 90Vac to 264Vac for nominal inputs like 100Vac, 110Vac, 120Vac, 200Vac, 208Vac, 220Vac, 230Vac, and 240Vac at a frequency of 47-63Hz, with an input overvoltage tolerance of 264-300Vac for up to 500ms, a turn-ON voltage of 75Vac, and a shutdown voltage of 54Vac. This part of the PIM-series measures W36mm x H90mm x D91mm, has an IP20 degree of protection, and is housed in polycarbonate (PC). It supports a single-phase (1AC) network, has a net width of 36mm, and offers a rated power of 60W at -10 to +60°C, which derates linearly to 45.6W at +70°C. The output voltage (DC) is adjustable between 12Vdc and 15Vdc, with protection functions including output overvoltage protection and overload/short-circuit protection. Efficiency rates are 0.907 at 230Vac input and 0.902 at 120Vac input. Current consumption is 0.6A at 230Vac input (full output), 1A at 120Vac input (full output), and 1.15A at 100Vac input (full output), with a peak inrush of 44A at 230Vac input and 18A at 120Vac input. The unit has a start-up delay of 50-60ms, a rise time of 18ms max at nominal input with full constant current load and 0mF load capacitance, and a hold time of 107ms at 230Vac input. Power dissipation/losses are 6.2W at 230Vac input and 6.5W at 120Vac input under full output load. Electrical durability is noted at various conditions, with the highest being 724000 hours at 25°C, 2.5A, 1AC 230Vac input. Ripple is specified at 100mVpp (20Hz...20MHz; 50Ω), and the output stage capacitance is 2200µF. | Puls | Quick Quote | ||
| CT10.481 PULS CT10.481 is a power supply unit designed for DIN rail mounting, featuring an aluminium housing. It operates within an ambient air temperature range of -25 to +70°C and has a net width of 62mm. The unit consumes 0.6A with a 3 x 480Vac input and 0.7A with a 3 x 400Vac input, both at full 48Vdc output, with a peak inrush current of 10A. It boasts an efficiency of 0.929 for 3x480Vac input and 0.928 for 3x400Vac input. The dimensions are W62mm x H124mm x D117mm. It includes a 90ms start-up delay, a 55ms rise time at nominal input with a constant full current load and 0mF load capacitance, and a 140ms rise time with 5mF load capacitance. The unit features output overvoltage protection, an active input inrush current limiter, and supports series/parallel operation for increased output power. It is resistant to back-feeding loads up to 63V. Power dissipation/losses are 18.3W for 3x480Vac input and 18.6W for 3x400Vac input at full output load. The output stage capacitance is 2400µF. Electrical durability ranges from 78,000 to 704,000 hours depending on the operating conditions. The ripple is 100mVpp (20Hz...20MHz; 50Ω). This AC/DC power supply unit/converter offers a 20% power reserve and includes a DC-OK relay contact output. It features screw-clamp connections and supports a supply voltage of 323Vac-576Vac (wide range; 3-phase input) with a rated current of 6A at 48Vdc from -25 to +45°C and 3.75A at 48Vdc from -25 to +70°C. The output voltage is adjustable between 48Vdc and 56Vdc, with a hold time of 54ms at 3x480Vac input and 34ms at 3x400Vac input. | Puls | Quick Quote | ||
| CP10.122 PULS CP10.122 is a DIN rail mounting power supply unit enclosed in an aluminium housing, designed for an ambient air temperature range of -25 to +70°C. It features a net width of 39mm and dimensions of W39mm x H124mm x D117mm. The unit has a current consumption of 11A peak max. inrush at 230Vac input and 7A peak max. inrush at 120Vac input. Its efficiency rates are 0.943 at 230Vac input, 0.928 at 120Vac input, and 0.921 at 100Vac input. The CP10.122 offers a start-up delay of 240-300ms for 100-230Vac input, with rise times of 18ms and 35ms under specified conditions. It includes protection functions such as output overvoltage protection and overload/short-circuit current protection, with capabilities for series/parallel operation and resistance to back-feeding loads up to 25V. Power dissipation/losses are 11.6W at 230Vac input and 14.9W at 120Vac input, with an output stage capacitance of 5350µF. The electrical durability varies with conditions, reaching up to 534000 hours. The ripple is specified at 50mVpp (20Hz...20MHz; 50Ω). This AC/DC power supply unit, part of the CP-series, features a 20% power reserve, shutdown input, extended DC input, and DC-OK relay contact output, with screw-clamp connections. It supports a supply voltage range of 88Vdc-180Vdc and 85Vac-264Vac, with a rated current of 16A at 12Vdc, and offers a rated power of 192W. The output voltage is adjustable between 12Vdc and 15Vdc, with a 200mV turn-ON overshoot and a hold time of 50ms. It is suitable for single-phase (1AC) or DC networks. | Puls | Quick Quote | ||
| CT20.241 Puls Power Supply, 3-Phase Input, 24V, 1 | Puls | Quick Quote | ||
