831-3209/007-000 WAGO Electrical Connector Accessories

831-3209/007-000 on Powermatic Associates
WAGO

Part#:831-3209/007-000

Manufacturer:WAGO

Product Lifecycle:Active

Get a quick Quote!

1-conductor male connector; Push-in CAGE CLAMP®; 10 mm²; Pin spacing 7.62 mm; 9-pole; 100% protected against mismating; DIN-35 rail mounting; 10,00 mm²; light gray

About the manufacturer: WAGO is one of the manufacturers that offers Electrical Connector Accessories that you can order at Powermatic Associates site. WAGO is the global leader in spring clamp technology for electrical connections and ranks among the top suppliers of components for industrial and building automation. With 28 companies and 9 production facilities employing around 9,000 people worldwide, we ensure expert advice and close customer relationships.

Check out the 831-3209/007-000 WAGO price in the box on the right side or send a quick quote.

Product Details

  • Weight
    61.32001613 g
  • Country Of Origin
    Germany
  • HTS Code
    85366990990
  • Width
    2.774 inches, 70.46 millimeters
  • Weight
    61.308 grams
  • Voltage
    800 volts
  • Strip Length
    0.59 inches, 15 millimeters
  • Package Type
    Box
  • Mounting Type
    DIN-35 Rail
  • Height
    39 millimeters
  • Flammability Class
    V0
  • Insulation Material
    Polyamide
  • Depth
    1.811 inches, 46 millimeters
  • Contact Type
    Tin
  • Current
    41 amperes
  • Country of Origin
    Poland
  • Contact Material
    Copper
  • Connection Type
    For Conductor
  • Conductor Size
    10 millimeters, 8 american wire gauge
  • Actuator
    Operating Tool
  • Color
    Gray

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

831-3209/007-000 Description

WAGO 831-3209/007-000 is a connector part of the MCS - MULTI CONNECTION SYSTEM, designed without breaking capacity as per DIN EN 61984, indicating it should not be connected or disconnected under load or when live. It adheres to IEC/EN 60664-1 standards, with nominal voltages of 800V (III/3) and 1000V (II/2, III/2), rated impulse voltage of 8kV, and a rated current of 41A. UL and CSA approvals are included, with a rated voltage of 600V and rated currents of 42A (UL) and 41A (CSA) for Use Group C. The connector features a single connection type with push-in CAGE CLAMP technology, supporting solid and fine-stranded conductors ranging from 0.5 to 10mm2 (20 to 8 AWG), and fine-stranded conductors with both insulated and uninsulated ferrules from 0.5 to 6mm2. It has a 9-pole configuration, a pin spacing of 7.62mm, and dimensions of 70.46mm in width, 39mm in height, and 46mm in depth. The connector is designed for DIN-35 rail mounting, includes variable coding, anti-rotation protection, and is made from light gray Polyamide (PA66) with a flammability class of UL94 V0. The contact material is Electrolytic Copper with a tin plating. It operates within a temperature range of -60 to +105°C and is RoHS compliant. The product is packaged in boxes of 12 pieces, with a country of origin in Poland and a GTIN of 4050821536321.
