733-204 WAGO Electrical Connector Accessories

733-204 on Powermatic Associates
WAGO

Part#:733-204

Manufacturer:WAGO

Category:Electrical Connector Accessories

Product Lifecycle:Active

Product description

733-204 WAGO - 1-conductor male connector; CAGE CLAMP®; 0.5 mm²; Pin spacing 2.5 mm; 4-pole; 100% protected against mismating; 0,50 mm²; light gray

Product Details

  • Weight
    2.12800056 g
  • Country Of Origin
    Poland
  • HTS Code
    85366990990
  • Width
    0.492 inches, 12.5 millimeters
  • Weight
    2.128 grams
  • Strip Length
    0.24 inches, 6 millimeters
  • Voltage
    100 volts, 150 volts
  • Package Type
    Box
  • Insulation Material
    Polyamide
  • Flammability Class
    V0
  • Height
    0.465 inches, 11.8 millimeters
  • Depth
    0.799 inches, 20.3 millimeters
  • Current
    4 amperes, 6 amperes
  • Country of Origin
    Poland
  • Contact Type
    Tin
  • Contact Material
    Copper
  • Connection Type
    For Conductor
  • Conductor Size
    0.5 millimeters, 20 american wire gauge
  • Color
    Gray
  • Actuator
    Operating Tool

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 733-204 on Powermatic Associates is $4.30. Order now.


About the product

WAGO 733-204 is a connector part of the MCS - MULTI CONNECTION SYSTEM, designed without breaking capacity as per DIN EN 61984, indicating it should not be connected or disconnected under load or when live. It adheres to IEC/EN 60664-1 standards, with nominal voltages of 100V, 160V, and 320V for different overvoltage categories and pollution degrees, and a rated current of 6A. The UL and CSA ratings specify a rated voltage of 150V and a rated current of 4A for Use Group B. This part features 4 connection points, supports a single connection type with one level, and utilizes CAGE CLAMP technology for connection, requiring an operating tool for actuation. It accommodates solid and fine-stranded conductors ranging from 0.08 to 0.5mm2 (28 to 20 AWG), with specific sizes for conductors with insulated or uninsulated ferrules. The connector has a 4-pole configuration, with a pin spacing of 2.5mm, and dimensions of 12.5mm in width, 11.8mm in height, and 20.3mm in depth. It includes variable coding, anti-rotation protection, and mismating protection, but lacks a locking mechanism for the plug-in connection. The connector is made from light gray Polyamide (PA66), with a chrome-nickel spring steel clamping spring, electrolytic copper contacts with tin plating, and meets UL94 V0 flammability standards. It operates within a temperature range of -60 to +100°C, has a fire load of 0.043MJ, and weighs 2.1g. This product is RoHS compliant, packaged in boxes of 200 pieces, and manufactured in Poland with a GTIN of 4044918849548.


This item can ship within 0 day!

Manufacturer warranty

733-204 WAGO

$4.30

Your price can be lower.
Log in or Create account to check your discount

Stock:

0

Select Qty:

$4.30

$4.30 each

Worldwide Shipping and Delivery


Secure Payment Processing


Warranty
