2734-114/037-000 WAGO Electrical Connector Accessories

2734-114/037-000 on Powermatic Associates
WAGO

Part#:2734-114/037-000

Manufacturer:WAGO

Category:Electrical Connector Accessories

Product Lifecycle:Active

Product description

2734-114/037-000 WAGO - 1-conductor female connector; push-button; Push-in CAGE CLAMP®; 1.5 mm²; Pin spacing 3.5 mm; 14-pole; 100% protected against mismating; Lateral locking levers; 1,50 mm²; light gray

Product Details

  • Weight
    12.44800327 g
  • Country Of Origin
    Poland
  • HTS Code
    85366990990
  • Width
    2.362 inches, 60 millimeters
  • Strip Length
    0.35 inches, 9 millimeters
  • Voltage
    160 volts, 300 volts
  • Weight
    12.448 grams
  • Package Type
    Box
  • Insulation Material
    Polyamide
  • Height
    0.531 inches, 13.5 millimeters
  • Flammability Class
    V0
  • Depth
    0.803 inches, 20.4 millimeters
  • Contact Type
    Tin
  • Country of Origin
    Poland
  • Current
    10 amperes, 10 amperes
  • Contact Material
    Copper Alloy
  • Connection Type
    For Conductor
  • Conductor Size
    1.5 millimeters, 16 american wire gauge
  • Color
    Gray
  • Actuator
    Push-button

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 2734-114/037-000 on Powermatic Associates is $16.52. Order now.


About the product

WAGO 2734-114/037-000 is a connector part of the MCS - MULTI CONNECTION SYSTEM, designed without breaking capacity as per DIN EN 61984, indicating it should not be connected or disconnected under load or when live. It adheres to IEC/EN 60664-1 standards, with nominal voltages of 160V and 320V under different conditions, rated impulse voltage of 2.5kV, and a rated current of 10A. UL and CSA approvals are included, with ratings of 300V and 10A for both UL and CSA under different use groups. This connector features 14 connection points, a single connection type, and one level, utilizing Push-in CAGE CLAMP technology with push-button actuation. It supports solid and fine-stranded conductors ranging from 0.2 to 1.5mm2 (24 to 16 AWG), including options for both insulated and uninsulated ferrules. The physical dimensions include a pin spacing of 3.5mm, width of 60mm, height of 13.5mm, and depth of 20.4mm. It offers variable coding, anti-rotation protection, and a female connector/socket type with mismating protection but does not allow plugging without loss of pin spacing. The locking mechanism is a locking lever. The connector is made from light gray Polyamide (PA66), with a flammability class of UL94 V0, and uses Chrome-Nickel spring steel for the clamping spring and a copper alloy with tin plating for contacts. It operates within a temperature range of -60 to +100°C, has a fire load of 0.244MJ, and weighs 12.7g. It is RoHS compliant without exemptions, packaged in boxes of 25 pieces, and has a country of origin of PL.
