2721-203/037-000 WAGO Electrical Connector Accessories

2721-203/037-000 on Powermatic Associates
WAGO

Part#:2721-203/037-000

Manufacturer:WAGO

Product Lifecycle:Active

Get a quick Quote!

1-conductor female connector; push-button; Push-in CAGE CLAMP®; 2.5 mm²; Pin spacing 7.5 mm; 3-pole; 100% protected against mismating; Lateral locking levers; 2,50 mm²; light gray

About the manufacturer: WAGO is one of the manufacturers that offers Electrical Connector Accessories that you can order at Powermatic Associates site. WAGO is the global leader in spring clamp technology for electrical connections and ranks among the top suppliers of components for industrial and building automation. With 28 companies and 9 production facilities employing around 9,000 people worldwide, we ensure expert advice and close customer relationships.

Check out the 2721-203/037-000 WAGO price in the box on the right side or send a quick quote.

Product Details

  • Weight
    7.289001917 g
  • Country Of Origin
    Poland
  • HTS Code
    85366990990
  • Width
    1.445 inches, 36.7 millimeters
  • Weight
    7.259 grams
  • Voltage
    300 volts, 500 volts
  • Strip Length
    0.43 inches, 11 millimeters
  • Package Type
    Box
  • Insulation Material
    Polyamide
  • Height
    0.591 inches, 15 millimeters
  • Current
    15 amperes, 16 amperes
  • Flammability Class
    V0
  • Depth
    1.173 inches, 29.8 millimeters
  • Country of Origin
    Poland
  • Contact Type
    Tin
  • Contact Material
    Copper Alloy
  • Connection Type
    For Conductor
  • Color
    Gray
  • Conductor Size
    12 american wire gauge, 2.5 millimeters
  • Actuator
    Push-button

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

2721-203/037-000 Description

WAGO 2721-203/037-000 is a connector part of the MCS - MULTI CONNECTION SYSTEM, designed without breaking capacity as per DIN EN 61984, indicating it should not be connected or disconnected under load or when live. It adheres to IEC/EN 60664-1 standards, with nominal voltages of 500V (III/3), 630V (III/2), and 1000V (II/2), all with a rated impulse voltage of 6kV and a rated current of 16A. UL ratings include a 300V rated voltage and 15A rated current for Use Group B, with variations for other groups, and CSA ratings mirror these for similar groups. The connector features 3 connection points, supports a single connection type across one level, and utilizes Push-in CAGE CLAMP technology with push-button actuation. It accommodates solid and fine-stranded conductors ranging from 0.2 to 2.5mm2 (24 to 12 AWG), with specific allowances for ferruled conductors. Physical specifications include a 7.5mm pin spacing, dimensions of 36.7mm width, 15mm height, and 29.8mm depth, and it offers features like variable coding, anti-rotation protection, and mismating protection. The connector is made from light gray Polyamide (PA66), with a chrome-nickel spring steel clamping spring, copper alloy contacts, and tin plating. It operates within a temperature range of -60 to +100°C, has a fire load of 0.173MJ, and weighs 7.3g. Packaged in boxes of 50, it is RoHS compliant without exemptions, and its country of origin is Poland.
