2202-1611/1000-541
Wago 2202-1611/1000-541 is a terminal designed for feed-through terminal block applications, featuring push-in CAGE CLAMP spring connections for quick and secure wiring. It operates on a supply voltage of 12-30Vdc, indicated by an LED, and supports a rated current of 6.3A according to IEC and Ex e II standards, and 10A according to UL and CSA standards. This terminal is designed with a single deck/level, includes a fused-disconnect with a lever type and Normally Open (NO) auxiliary contacts sized 5x20mm, and a blown-fuse LED indicator. It comes with a built-in end plate, ensuring the terminal is closed on both sides, and is suitable for operation in ambient air temperatures ranging from -35°C to +70°C. The terminal is compatible with DIN-35 rail mounting, measures H66.1mm x W6.2mm x D57.6mm, and is designed to accommodate 0.25mm2 to 4mm2 fine stranded or solid conductors, as well as #22AWG to #12AWG fine stranded or solid conductors with a 2.5mm2 nominal cross-section. The material used is Polyamide (PA) 66, and it is designed for 2-wires (1 push-in + 1 push-in) connections. The rated insulation voltage stands at 250 V for IEC, UL, and CSA, and 275 V for Ex e II, with a protection function width of 6.2 mm. The product is part of the TOPJOB S series, indicated by its UNSPSC code.
