2616-1352 WAGO Industrial Automation Components
Part#:2616-1352
Manufacturer:WAGO
Category:Industrial Automation Components
Product Lifecycle:Active
Product description
2616-1352 WAGO - PCB terminal block; lever; Pin spacing 15 mm; double pinning; 2-pole; Push-in CAGE CLAMP®; gray
Product Details
- Weight 22.21700584 g
- Country Of Origin Germany
- HTS Code 85369010000
- Width 1.043 inches, 26.5 millimeters
- Weight 22.345 grams
- Voltage 300 volts, 800 volts
- Strip Length 0.79 inches, 20 millimeters
- Package Type Box
- Insulation Material Polyamide
- Height 1.465 inches, 37.2 millimeters
- Depth 1.26 inches, 32 millimeters
- Current 76 amperes, 78 amperes
- Flammability Class V0
- Country of Origin Germany
- Contact Type Tin
- Contact Material Copper
- Conductor Size 16 millimeters, 4 american wire gauge
- Color Gray
- Actuator Lever
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 2616-1352 on Powermatic Associates is $7.05. Order now.
About the product
WAGO 2616-1352 is an automation part with a short circuit breaking rating as per IEC/EN 60664-1. It features nominal voltages of 800V (III/3) and 1000V (II/2 & III/2), with rated impulse voltages of 8kV for both overvoltage categories III/2 and III/3. The rated current according to IEC/EN is 76A. Under UL 1059 approvals, it has rated voltages of 300V for Use Groups B and C, and 600V for Use Group D, with corresponding rated currents of 78A for Groups B and C, and 5A for Group D. CSA approvals mirror these specifications with slight variations in rated currents. The part includes 2 connection points, supports a single connection type across one level, and utilizes Push-in CAGE CLAMP technology with lever actuation. It accommodates solid and fine-stranded conductors ranging from 0.75 to 25mm2 (18 to 4 AWG), with specific capacities for ferruled conductors. The strip length for connection is between 18 to 20mm, and it is designed for 0° conductor connection direction to PCB. Physical specifications include a pin spacing of 15mm, dimensions of 26.5mm in width, 37.2mm in height, 32mm in depth, and a solder pin length of 4mm. The terminal is made from Polyamide (PA66) in gray, with a chrome-nickel spring steel clamping spring, electrolytic copper contacts plated with tin, and an orange actuator. It operates within a temperature range of -60 to +105°C, has a fire load of 0.347MJ, and weighs 22.4g. The product is RoHS compliant, packaged in boxes of 44 pieces, and has a GTIN of 4055143860284.
