231-318/102-000 WAGO Electrical Connector Accessories

WAGO 231-318/102-000 1-conductor female connector; CAGE CLAMP®; 2.5 mm²; Pin spacing 5.08 mm; 18-pole; with integrated end plate; 2,50 mm²; orange
WAGO

Part#:231-318/102-000

Manufacturer:WAGO

Product Lifecycle:Active

Get a quick Quote!

1-conductor female connector; CAGE CLAMP®; 2.5 mm²; Pin spacing 5.08 mm; 18-pole; with integrated end plate; 2,50 mm²; orange

About the manufacturer: WAGO is one of the manufacturers that offers Electrical Connector Accessories that you can order at Powermatic Associates site. WAGO is the global leader in spring clamp technology for electrical connections and ranks among the top suppliers of components for industrial and building automation. With 28 companies and 9 production facilities employing around 9,000 people worldwide, we ensure expert advice and close customer relationships.

Check out the 231-318/102-000 WAGO price in the box on the right side or send a quick quote.

Product Details

  • Weight
    32.3130085 g
  • Country Of Origin
    Germany
  • HTS Code
    85366990990

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

231-318/102-000 Description

WAGO 231-318/102-000 is a connector part of the MCS - MULTI CONNECTION SYSTEM, designed without breaking capacity as specified in DIN EN 61984, indicating it should not be connected or disconnected under load or when live. It adheres to IEC/EN 60664-1 standards, with nominal voltages of 320V and 630V under different conditions, rated impulse voltage of 4kV, and a rated current of 16A. UL and CSA approvals include ratings of 300V and 600V with currents ranging from 10A to 15A depending on the use group. It features 18 connection points, a single connection type with CAGE CLAMP technology, and supports solid and fine-stranded conductors of various sizes. The connector has a pin spacing of 5.08mm, dimensions of 91.44mm in width, 14.3mm in height, and 26.45mm in depth, and includes variable coding and anti-rotation protection. The female connector/socket is made from orange Polyamide (PA66) with a tin-plated copper alloy contact material and a chrome-nickel spring steel clamping spring. It has a flammability class of UL94 V0, weighs 32.3g, and operates within a temperature range of -60 to +85°C. The product is RoHS compliant, packaged in boxes of 10 pieces, and has a GTIN of 4044918349925.

Manufacturer warranty
