2060-953/028-000 WAGO Electrical Connector Accessories

2060-953/028-000 on Powermatic Associates
WAGO

Part#:2060-953/028-000

Manufacturer:WAGO

Category:Electrical Connector Accessories

Product Lifecycle:Active

Product description

2060-953/028-000 WAGO - Board-to-Board Link; Pin spacing 4 mm; 3-pole; Length: 28 mm; white

Product Details

  • Weight
    0.690000181 g
  • Country Of Origin
    China
  • HTS Code
    85369010000
  • Width
    0.449 inches, 11.4 millimeters
  • Weight
    0.690 grams
  • Voltage
    63 volts
  • Package Type
    Box
  • Insulation Material
    Polyamide
  • Height
    0.102 inches, 2.6 millimeters
  • Flammability Class
    V0
  • Depth
    1.102 inches, 28 millimeters
  • Current
    9 amperes
  • Country of Origin
    China
  • Contact Type
    Silver
  • Color
    White
  • Contact Material
    Copper Alloy

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 2060-953/028-000 on Powermatic Associates is $0.70. Order now.


About the product

WAGO 2060-953/028-000 is a component designed for SMD PCB terminal blocks, specifically compatible with the 2060-45x series but not the 2060-40x. It operates with a nominal voltage of 63V in overvoltage category III/3, a rated impulse voltage of 2.5kV, and a rated current of 9A according to IEC/EN 60664-1 standards. For overvoltage category III/2, it has a rated voltage of 160V and the same rated impulse voltage. In category II/2, the nominal voltage increases to 320V with a rated surge voltage of 2.5kV. According to UL 1977 standards, it has a rated voltage of 250V and a rated current of 9A. The part features three total potentials, a 3-pole connection, and a pin spacing of 4mm. Its dimensions are 11.4mm in width, 2.6mm in height, and 28mm in depth, with a weight of 0.7g. It supports up to 10 mating cycles and is made from white polyamide (PA66) with a V0 flammability class. The contact material is a copper alloy with silver plating. It operates within a temperature range of -60 to +105°C, is RoHS compliant without exemptions, and comes in a box of 375 pieces with the country of origin being China.
