TX710-P3CV01 Turck LCD Touch Panels - HMI Panel

Name: TX710-P3CV01
Brand: Turck

Turck TX710-P3CV01 TX710-P3CV01 TX700 HMI/PLC Series, 10 Display - CODESYS V3 PLC with TARGET and WEB VISU, High-Quality Metal Housing and Glass Front with a Capacitive Touch"

Part#:TX710-P3CV01

Manufacturer:Turck

Alt. Part#:100002031

Product Lifecycle:Active

Get a quick Quote!

TX710-P3CV01 TX700 HMI/PLC Series, 10 Display - CODESYS V3 PLC with TARGET and WEB VISU, High-Quality Metal Housing and Glass Front with a Capacitive Touch"

About the manufacturer: Turck is one of the manufacturers that offers LCD Touch Panels - HMI Panel that you can order at Powermatic Associates site. Turck is a leading provider of sensor, fieldbus, and connectivity technologies, along with interface technology, human-machine interfaces (HMI), and RFID systems. We offer innovative solutions for factory and process automation requirements, guaranteeing top-notch performance.

Check out the TX710-P3CV01 Turck price in the box on the right side or send a quick quote.

Product Details

Weight
2440 g
Product Family
TX700
Fieldbus master
PROFINET, EtherNet/IP, Modbus TCP, Modbus RTU, CANopen, SAE J1939, EtherCAT
Programming
CODESYS V3
Protection class
IP66 front, IP20 rear
Fieldbus slave
Modbus TCP, Modbus RTU
Touchscreen
Capacitive, Glass front
Diagonal screen size
10 ″
Application area
Factory Automation
Format
16:9
Device function
HMI/PLC

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

TX710-P3CV01 Description

Turck TX710-P3CV01 is a capacitive touchscreen operator interface (HMI) from the TX series, designed with CODESYS V3 P.L.C. runtime WebVisu. It features a metal housing and offers multiple connection options including 3 x RJ45 connectors for Ethernet 10/100Mbit, 1 x serial interface port supporting RS-232, RS-485, and RS-422, and 1 x USB host port. The device operates on a supply voltage of 10-32Vdc, with 24Vdc nominal, and can function in ambient air temperatures ranging from -20 to +60°C. It comes equipped with a memory capacity of 4096MB (FLASH) and 1024MB (RAM), ensuring ample storage for applications. The TX710-P3CV01 has a degree of protection rated at IP20 and measures 282 mm in width, 197 mm in height, and 56 mm in depth.
