REM-E-195T10S-IOL32B-H1141 Turck Encoders

Name: REM-E-195T10S-IOL32B-H1141
Brand: Turck
Price: 618.2 USD
Availability: BackOrder

REM-E-195T10S-IOL32B-H1141 on Powermatic Associates

Part#:REM-E-195T10S-IOL32B-H1141

Manufacturer:Turck

Category:Encoders

Alt. Part#:100021184

Product Lifecycle:Active

Get a quick Quote!

REM-E-195T10S-IOL32B-H1141 Turck - REM-E-195T10S-IOL32B-H1141 Absolute Rotary Encoder - Multiturn, IO-Link, Efficiency Line

About the manufacturer: Turck is one of the manufacturers that offers Encoders that you can order at Powermatic Associates site. Turck is a leading provider of sensor, fieldbus, and connectivity technologies, along with interface technology, human-machine interfaces (HMI), and RFID systems. We offer innovative solutions for factory and process automation requirements, guaranteeing top-notch performance.

Check out the REM-E-195T10S-IOL32B-H1141 Turck price in the box on the right side or send a quick quote.

Product Details

Weight
370 g
Country Of Origin
DEU
HTS Code
9032894000
Weight
370 grams
Operating Voltage
18 volts, 30 volts
Ambient Temperature
-20 degrees celsius, 70 degrees celsius
Country of Origin
Germany
Housing material
Die-cast zinc
Protection class
IP64
Protection class shaft
IP64
Ambient temperature
-20…+70 °C
Electrical connection
Connector, M12 × 1
Communication protocol
IO-Link
Technology
Magnetic
Operating voltage
18…30 VDC
Shaft Type
Solid shaft
Flange diameter
Ø 58 mm
Flange type
Synchro flange
Shaft diameter D [mm]
10 mm
Output type
Absolute multiturn

Encoder line

Efficiency-Line

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

REM-E-195T10S-IOL32B-H1141 Description

Absolute Rotary Encoder - Multiturn, IO-Link, Efficiency Line, Ø 58 mm servo flange, Solid shaft, Ø 10mm x 20mm, Optical measuring principle, Shaft material, stainless steel, , Protection class IP64 on housing and shaft side, ‐20…+70 °C, Max. 4000 rpm (continuous operation 2000 rpm), Energy harvesting technology, 18….30 VDC, M12 x 1 male connection, 4-pin, Singleturn resolution 14 bit scalable, default 14 bit, Multiturn resolution scalable only to 18 bits over total resolution, default 18 bits, Total resolution 32 bit scalable, default 32 bit
